{"id":8115271205044,"title":"Voice Playback Module, DC 6V-35V Voice Module Digital Amplifier Module TF Card Accessories","handle":"voice-playback-module-dc-6v-35v-voice-module-digital-amplifier-module-tf-card-accessories","description":"\u003ch3\u003eVoice Playback Module, DC 6V-35V Voice Module Digital Amplifier Module TF Card Accessories\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFeatures: Supports MP3 and WAV decoding format. 2. Supported sampling\nfrequency (KHz): 8\/11.025\/12\/16\/22.05\/24\/32\/44.1\/48 3\u0026gt;.24-bit DAC output,\nsupport dynamic range 90dB, SNR support 85dB. 4. Support FAT16\/FAT32 file\nsystem with maximum 32Gbit (4MByte) TF card and 32Gbit (4MByte) U disk. 5.\nSupports the voice transmission function of the UART serial interface. It can\ncontrol playback, pause, selection, volume and other functions, the largest\nselection of 65535 songs. The baud rate is 9600 bit\/s. 6. Support I\/O trigger\nfunction, 8-bit I\/O ports can trigger 8 pieces of music or 8 I\/O combinations\nto trigger 255 songs. 7\u0026gt;.Support One_line single bus serial port control,\nwhich can control playback, pause, selection, volume increase and decrease and\nother functions. 8\u0026gt;.Supports 3 configuration I\/O for mode selection to create\n7 working modes. 9. Built-in 20W Class D amplifier circuit and can directly\ndrive 4ohm \/ 20w 8ohm \/ 10w speakers. Package list: 1 x DY-HV20T voice\nplayback module. Note: 1. Please allow for a 1-2 cm margin of error due to\nmanual measurement. 2. Due to the different monitor and light effect, the\nactual colour of the item may be slightly different from the colour shown in\nthe pictures. Thank you for your understanding.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eDY-HV20T is an intelligent voice module. It integrates I\/O subsection triggering, UART control of serial interface, ONE_line single bus control of serial interface. Built-in 20W Class D amplifier circuit and can directly drive 4ohm\/20w-8ohm\/10w speakers.\u003c\/li\u003e\n \u003cli\u003eSupports MP3, WAV decoding format. Max. Support for 32Gbit (4MByte) TF card storage, can connect the computer to update the TF card to save audio files via USB cable. 3.5mm audio interface, U disk interface, micro USB download interface, button module in one module\u003c\/li\u003e\n \u003cli\u003eSupports the voice transmission function of the UART serial interface. It can control playback, pause, selection, volume and other functions, the largest selection of 65535 songs. The baud rate is 9600 bit\/s. Support I\/O trigger function, 8-bit I\/O ports can trigger 8 music pieces or 8 I\/O combinations to trigger 255 songs.\u003c\/li\u003e\n \u003cli\u003eSupports One_line single bus serial port control, which can control playback, pause, selection, volume increase and decrease and other functions. Supports 3 configuration I\/O for mode selection to create 7 working modes. Built-in 20W Class D amplifier circuit and can directly drive 4ohm\/20w-8ohm\/10w speakers.\u003c\/li\u003e\n \u003cli\u003eAfter-sales service: Thank you for your purchase. If you have a problem, please feel free to contact us at any time. We promise you the satisfactory solutions within 24 hours.\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2026-09-02T11:18:51+10:00","created_at":"2026-09-01T23:42:49+10:00","vendor":"MiOYOOW","type":"Audio Amplifier","tags":["industrial_DE_Aug2026"],"price":13300,"price_min":13300,"price_max":13300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44374991470772,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B09SHRHQT7","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Voice Playback Module, DC 6V-35V Voice Module Digital Amplifier Module TF Card Accessories","public_title":null,"options":["Default Title"],"price":13300,"weight":10,"compare_at_price":null,"inventory_management":"shopify","barcode":"760606355637","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/de-B09SHRHQT7.jpg?v=1788270171","\/\/auspowers.com\/cdn\/shop\/files\/71LOfO8EcZL.jpg?v=1788270171","\/\/auspowers.com\/cdn\/shop\/files\/510MWSacNYL.jpg?v=1788270171","\/\/auspowers.com\/cdn\/shop\/files\/61I4wXlHBSL.jpg?v=1788270171","\/\/auspowers.com\/cdn\/shop\/files\/61p64gq3_xL.jpg?v=1788270171","\/\/auspowers.com\/cdn\/shop\/files\/61T-EPz_B0L.jpg?v=1788270171"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/de-B09SHRHQT7.jpg?v=1788270171","options":["Title"],"media":[{"alt":null,"id":33273144049844,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/de-B09SHRHQT7.jpg?v=1788270171"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/de-B09SHRHQT7.jpg?v=1788270171","width":1000},{"alt":null,"id":33273144082612,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71LOfO8EcZL.jpg?v=1788270171"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71LOfO8EcZL.jpg?v=1788270171","width":1000},{"alt":null,"id":33273144115380,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/510MWSacNYL.jpg?v=1788270171"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/510MWSacNYL.jpg?v=1788270171","width":1000},{"alt":null,"id":33273144148148,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61I4wXlHBSL.jpg?v=1788270171"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61I4wXlHBSL.jpg?v=1788270171","width":1000},{"alt":null,"id":33273144180916,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61p64gq3_xL.jpg?v=1788270171"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61p64gq3_xL.jpg?v=1788270171","width":1000},{"alt":null,"id":33273144213684,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61T-EPz_B0L.jpg?v=1788270171"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61T-EPz_B0L.jpg?v=1788270171","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eVoice Playback Module, DC 6V-35V Voice Module Digital Amplifier Module TF Card Accessories\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFeatures: Supports MP3 and WAV decoding format. 2. Supported sampling\nfrequency (KHz): 8\/11.025\/12\/16\/22.05\/24\/32\/44.1\/48 3\u0026gt;.24-bit DAC output,\nsupport dynamic range 90dB, SNR support 85dB. 4. Support FAT16\/FAT32 file\nsystem with maximum 32Gbit (4MByte) TF card and 32Gbit (4MByte) U disk. 5.\nSupports the voice transmission function of the UART serial interface. It can\ncontrol playback, pause, selection, volume and other functions, the largest\nselection of 65535 songs. The baud rate is 9600 bit\/s. 6. Support I\/O trigger\nfunction, 8-bit I\/O ports can trigger 8 pieces of music or 8 I\/O combinations\nto trigger 255 songs. 7\u0026gt;.Support One_line single bus serial port control,\nwhich can control playback, pause, selection, volume increase and decrease and\nother functions. 8\u0026gt;.Supports 3 configuration I\/O for mode selection to create\n7 working modes. 9. Built-in 20W Class D amplifier circuit and can directly\ndrive 4ohm \/ 20w 8ohm \/ 10w speakers. Package list: 1 x DY-HV20T voice\nplayback module. Note: 1. Please allow for a 1-2 cm margin of error due to\nmanual measurement. 2. Due to the different monitor and light effect, the\nactual colour of the item may be slightly different from the colour shown in\nthe pictures. Thank you for your understanding.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eDY-HV20T is an intelligent voice module. It integrates I\/O subsection triggering, UART control of serial interface, ONE_line single bus control of serial interface. Built-in 20W Class D amplifier circuit and can directly drive 4ohm\/20w-8ohm\/10w speakers.\u003c\/li\u003e\n \u003cli\u003eSupports MP3, WAV decoding format. Max. Support for 32Gbit (4MByte) TF card storage, can connect the computer to update the TF card to save audio files via USB cable. 3.5mm audio interface, U disk interface, micro USB download interface, button module in one module\u003c\/li\u003e\n \u003cli\u003eSupports the voice transmission function of the UART serial interface. It can control playback, pause, selection, volume and other functions, the largest selection of 65535 songs. The baud rate is 9600 bit\/s. Support I\/O trigger function, 8-bit I\/O ports can trigger 8 music pieces or 8 I\/O combinations to trigger 255 songs.\u003c\/li\u003e\n \u003cli\u003eSupports One_line single bus serial port control, which can control playback, pause, selection, volume increase and decrease and other functions. Supports 3 configuration I\/O for mode selection to create 7 working modes. Built-in 20W Class D amplifier circuit and can directly drive 4ohm\/20w-8ohm\/10w speakers.\u003c\/li\u003e\n \u003cli\u003eAfter-sales service: Thank you for your purchase. If you have a problem, please feel free to contact us at any time. We promise you the satisfactory solutions within 24 hours.\u003c\/li\u003e\n \u003c\/ul\u003e"}
