{"id":7239052066996,"title":"UTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator","handle":"utek-ut-211-port-powered-rs-232-to-rs-232-mini-size-photoelectric-isolator","description":" \u003ch1\u003eUTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator\u003c\/h1\u003e\n \u003ch3\u003e\n\u003cspan class=\"glyphicon glyphicon-list-alt\"\u003e\u003c\/span\u003e Description\u003c\/h3\u003e\n \u003cp\u003eUT-211 is a RS-232 serial port optoelectronic isolator. It adopts advanced\noptoelectronic isolation technology, maximally protects RS-232 serial\ninterface devices from bad environment damage, such as ground loop circuit\nvoltage, surge, lightning, ESD, hot-plug and electromagnetic interference,\netc. The damage of RS-232 port is related to communication hardware. The\nreasons 90% are converged on above mentioned. For example, device A connects\ndevice B with RS-232 port, if the voltage difference of ground line between A\nand B is up to 50V (usually up to 80V), RS-232 port will not working normal;\nthe isolated voltage of RS-232 port will reach 2,500Vrms instantly, together\nwith 500VDC continuous peak voltage difference; it also absorbs in ESD and\nelectromagnetic interference, so as to protect RS-232 port. The optoelectronic\nisolation technology is fully isolating the electrical devices and ground loop\ncircuit on both ends; it converts the electrical signal to optic signal, then\ntransmits the signal to another end, finally converts it back to electrical\nsignal. This protects the communication device from ground loop circuit and\nsurge interference, which greatly improve the reliability and stability of the\ncommunication system. UT-211 gets widely application in point to point RS-232\ncommunication system, UNIX multi-user system, monitoring system, and ATM for\npower, insurance, telecommunications, railway, post office, finance, banking,\nsecurities and program control, etc.\u003c\/p\u003e\n \u003cp\u003eFeatures:\u003c\/p\u003e\n \u003cul\u003e\n \u003cli\u003eStandards: RS-232 \u0026amp; CCITTV.24 asynchronous protocol Connector: two DB9 on both sides\u003c\/li\u003e\n\u003cli\u003eTransmission mode: asynchronous full-duplex, full transparent Isolated voltage: 2,500Vrms impulse or 500VDC\u003c\/li\u003e\n\u003cli\u003eBaudrate: 300bps-57,600bps Power: from RS-232(TXD, RTS or DTR)\u003c\/li\u003e\n\u003cli\u003eDimension: 62mm34mm18mm Weight: 30g\u003c\/li\u003e\n\u003cli\u003eOperating temperature: -40C to 85C Relative humidity: 5% to 95%\u003c\/li\u003e\n \u003c\/ul\u003e\n\n\n ","published_at":"2022-08-27T21:24:00+10:00","created_at":"2022-08-27T21:24:06+10:00","vendor":"U-Tek","type":"Serial Adapters","tags":["electronics3"],"price":15100,"price_min":15100,"price_max":15100,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":41799680950452,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B00GI9GS58","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"UTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator","public_title":null,"options":["Default Title"],"price":15100,"weight":91,"compare_at_price":null,"inventory_management":null,"barcode":"BC78525","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/products\/B00GI9GS58.jpg?v=1661672703","\/\/auspowers.com\/cdn\/shop\/products\/61laxUDVfeL.jpg?v=1661599446","\/\/auspowers.com\/cdn\/shop\/products\/610ZnoxcUdL.jpg?v=1661599446","\/\/auspowers.com\/cdn\/shop\/products\/41cxzxDXBcL.jpg?v=1661599446","\/\/auspowers.com\/cdn\/shop\/products\/41j3VMrI8yL.jpg?v=1661599446","\/\/auspowers.com\/cdn\/shop\/products\/41gp6guTtIL.jpg?v=1661599446"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/products\/B00GI9GS58.jpg?v=1661672703","options":["Title"],"media":[{"alt":"[Australia - AusPower] - UTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator ","id":26962810208436,"position":1,"preview_image":{"aspect_ratio":0.738,"height":1075,"width":793,"src":"\/\/auspowers.com\/cdn\/shop\/products\/B00GI9GS58.jpg?v=1661672703"},"aspect_ratio":0.738,"height":1075,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/B00GI9GS58.jpg?v=1661672703","width":793},{"alt":"[Australia - AusPower] - UTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator ","id":26956287738036,"position":2,"preview_image":{"aspect_ratio":0.738,"height":1075,"width":793,"src":"\/\/auspowers.com\/cdn\/shop\/products\/61laxUDVfeL.jpg?v=1661599446"},"aspect_ratio":0.738,"height":1075,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/61laxUDVfeL.jpg?v=1661599446","width":793},{"alt":"[Australia - AusPower] - UTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator ","id":26956287770804,"position":3,"preview_image":{"aspect_ratio":0.738,"height":1075,"width":793,"src":"\/\/auspowers.com\/cdn\/shop\/products\/610ZnoxcUdL.jpg?v=1661599446"},"aspect_ratio":0.738,"height":1075,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/610ZnoxcUdL.jpg?v=1661599446","width":793},{"alt":"[Australia - AusPower] - UTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator ","id":26956287803572,"position":4,"preview_image":{"aspect_ratio":0.744,"height":500,"width":372,"src":"\/\/auspowers.com\/cdn\/shop\/products\/41cxzxDXBcL.jpg?v=1661599446"},"aspect_ratio":0.744,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/41cxzxDXBcL.jpg?v=1661599446","width":372},{"alt":"[Australia - AusPower] - UTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator ","id":26956287836340,"position":5,"preview_image":{"aspect_ratio":0.78,"height":500,"width":390,"src":"\/\/auspowers.com\/cdn\/shop\/products\/41j3VMrI8yL.jpg?v=1661599446"},"aspect_ratio":0.78,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/41j3VMrI8yL.jpg?v=1661599446","width":390},{"alt":"[Australia - AusPower] - UTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator ","id":26956287869108,"position":6,"preview_image":{"aspect_ratio":1.114,"height":449,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/products\/41gp6guTtIL.jpg?v=1661599446"},"aspect_ratio":1.114,"height":449,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/41gp6guTtIL.jpg?v=1661599446","width":500}],"requires_selling_plan":false,"selling_plan_groups":[],"content":" \u003ch1\u003eUTEK UT-211 Port-Powered RS-232 to RS-232 Mini-Size PhotoElectric Isolator\u003c\/h1\u003e\n \u003ch3\u003e\n\u003cspan class=\"glyphicon glyphicon-list-alt\"\u003e\u003c\/span\u003e Description\u003c\/h3\u003e\n \u003cp\u003eUT-211 is a RS-232 serial port optoelectronic isolator. It adopts advanced\noptoelectronic isolation technology, maximally protects RS-232 serial\ninterface devices from bad environment damage, such as ground loop circuit\nvoltage, surge, lightning, ESD, hot-plug and electromagnetic interference,\netc. The damage of RS-232 port is related to communication hardware. The\nreasons 90% are converged on above mentioned. For example, device A connects\ndevice B with RS-232 port, if the voltage difference of ground line between A\nand B is up to 50V (usually up to 80V), RS-232 port will not working normal;\nthe isolated voltage of RS-232 port will reach 2,500Vrms instantly, together\nwith 500VDC continuous peak voltage difference; it also absorbs in ESD and\nelectromagnetic interference, so as to protect RS-232 port. The optoelectronic\nisolation technology is fully isolating the electrical devices and ground loop\ncircuit on both ends; it converts the electrical signal to optic signal, then\ntransmits the signal to another end, finally converts it back to electrical\nsignal. This protects the communication device from ground loop circuit and\nsurge interference, which greatly improve the reliability and stability of the\ncommunication system. UT-211 gets widely application in point to point RS-232\ncommunication system, UNIX multi-user system, monitoring system, and ATM for\npower, insurance, telecommunications, railway, post office, finance, banking,\nsecurities and program control, etc.\u003c\/p\u003e\n \u003cp\u003eFeatures:\u003c\/p\u003e\n \u003cul\u003e\n \u003cli\u003eStandards: RS-232 \u0026amp; CCITTV.24 asynchronous protocol Connector: two DB9 on both sides\u003c\/li\u003e\n\u003cli\u003eTransmission mode: asynchronous full-duplex, full transparent Isolated voltage: 2,500Vrms impulse or 500VDC\u003c\/li\u003e\n\u003cli\u003eBaudrate: 300bps-57,600bps Power: from RS-232(TXD, RTS or DTR)\u003c\/li\u003e\n\u003cli\u003eDimension: 62mm34mm18mm Weight: 30g\u003c\/li\u003e\n\u003cli\u003eOperating temperature: -40C to 85C Relative humidity: 5% to 95%\u003c\/li\u003e\n \u003c\/ul\u003e\n\n\n "}
