{"id":8034517811380,"title":"USB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB","handle":"usb-isolation-module-adum3160-2500v-isolation-1-5mbps-12mbps-low-full-speed-40-c-to-105-c-compatible-with-stm32-labview-matlab","description":"\u003ch3\u003eUSB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003e1. Product Parameters Isolation Voltage: 2500V RMS (UL 1577 Certified) Data\r\nRates: Low Speed (1.5Mbps), Full Speed (12Mbps) Operating Voltage: 4.5V-5.5V\r\nDC (VBUS Powered) Supply Current: 7mA (Max @1.5Mbps), 8mA (Max @12Mbps) ESD\r\nProtection: ±8kV (IEC 61000-4-2 Contact Discharge) CMTI: \u0026gt;25kV\/μs (Common-Mode\r\nTransient Immunity) Isolation Technology: ADI iCoupler Magnetic Coupling USB\r\nPorts: Type-A Female (Output), Type-B Female (Input) Operating Temperature:\r\n-40°C to +105°C Protection: Upstream Short-Circuit, Overvoltage Lockout\r\nCompliance: USB 2.0, RoHS, Automotive Grade 2. Pin Functions VBUS1: Input\r\nPower (4.5V-5.5V DC), Connects to Host VBUS GND1: Input Ground (Host Side\r\nReference) D+1\/D-1: Host-Side Data Lines (Bidirectional Differential Pair)\r\nVBUS2: Output Power (Isolated 5V DC), Connects to Peripheral VBUS GND2: Output\r\nGround (Peripheral Side Isolated Reference) D+2\/D-2: Peripheral-Side Data\r\nLines 3. Frequently Asked Questions Q1: Does this support USB 3.0 or high-\r\nspeed (480Mbps) devices? A1: No. Only USB 2.0 Low\/Full Speed (1.5Mbps\/12Mbps)\r\ndevices are compatible (e.g., keyboards, mice, serial adapters) . Q2: Can it\r\nbe hot-plugged during operation? A2: Yes. Supports USB hot-swapping without\r\nhost reboot. Ensure input voltage (VBUS1) is stable before peripheral\r\nconnection . Q3: Why does my PC fail to detect the peripheral after\r\ninstallation? A3: Check: ① VBUS1 voltage ≥4.5V (use regulated 5V power); ②\r\nPeripheral draws \u0026lt;100mA current (isolator max output: 180mA); ③ No pin\r\nmisalignment (GND1\/GND2 must be correctly referenced) .\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eHigh-Voltage Isolation2500V RMS isolation; UL 1577 certified; protects against electrical surges and short circuits\u003c\/li\u003e\r\n \u003cli\u003eFast and Reliable Data TransferSupports USB 2.0 low\/full speed (1.5Mbps\/12Mbps); 8mA max supply current at 12Mbps\u003c\/li\u003e\r\n \u003cli\u003eRobust ESD Protection8kV contact discharge protection; \u0026gt;25kV\/s common-mode transient immunity for stable operation\u003c\/li\u003e\r\n \u003cli\u003eWide Operating Temperature Range-40C to +105C; suitable for industrial Enviro nments and outdoor applications\u003c\/li\u003e\r\n \u003cli\u003eEasy Integration and CompatibilityWorks with USB 2.0 peripherals; hot-swappable without system reboot; 5V isolated output for peripheral power\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2026-02-28T19:45:21+11:00","created_at":"2026-02-28T19:45:17+11:00","vendor":"MusRock","type":"Current Sensors","tags":["industrial_selected_Nov2025"],"price":11300,"price_min":11300,"price_max":11300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44154551992500,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0FMNMWN86","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"USB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB","public_title":null,"options":["Default Title"],"price":11300,"weight":10,"compare_at_price":null,"inventory_management":"shopify","barcode":"USB Isolation Module ADUM3160 2500V","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/B0FMNMWN86.jpg?v=1775787143","\/\/auspowers.com\/cdn\/shop\/files\/41t9hyQHDQL.jpg?v=1772268320","\/\/auspowers.com\/cdn\/shop\/files\/41PfcIkxnEL.jpg?v=1772268320","\/\/auspowers.com\/cdn\/shop\/files\/31tSF9e7ORL.jpg?v=1772268320","\/\/auspowers.com\/cdn\/shop\/files\/517pn1SIMYL.jpg?v=1772268320"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/B0FMNMWN86.jpg?v=1775787143","options":["Title"],"media":[{"alt":"[Australia - AusPower] - USB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB ","id":32724252819636,"position":1,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/auspowers.com\/cdn\/shop\/files\/B0FMNMWN86.jpg?v=1775787143"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/B0FMNMWN86.jpg?v=1775787143","width":800},{"alt":"[Australia - AusPower] - USB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB ","id":32724252852404,"position":2,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/auspowers.com\/cdn\/shop\/files\/41t9hyQHDQL.jpg?v=1772268320"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/41t9hyQHDQL.jpg?v=1772268320","width":800},{"alt":"[Australia - AusPower] - USB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB ","id":32724252885172,"position":3,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/auspowers.com\/cdn\/shop\/files\/41PfcIkxnEL.jpg?v=1772268320"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/41PfcIkxnEL.jpg?v=1772268320","width":800},{"alt":"[Australia - AusPower] - USB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB ","id":32724252917940,"position":4,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/auspowers.com\/cdn\/shop\/files\/31tSF9e7ORL.jpg?v=1772268320"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/31tSF9e7ORL.jpg?v=1772268320","width":800},{"alt":"[Australia - AusPower] - USB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB ","id":32724252950708,"position":5,"preview_image":{"aspect_ratio":1.0,"height":800,"width":800,"src":"\/\/auspowers.com\/cdn\/shop\/files\/517pn1SIMYL.jpg?v=1772268320"},"aspect_ratio":1.0,"height":800,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/517pn1SIMYL.jpg?v=1772268320","width":800}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eUSB Isolation Module ADUM3160 2500V Isolation 1.5Mbps\/12Mbps Low\/Full Speed -40°C to +105°C Compatible with STM32 LabVIEW MATLAB\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003e1. Product Parameters Isolation Voltage: 2500V RMS (UL 1577 Certified) Data\r\nRates: Low Speed (1.5Mbps), Full Speed (12Mbps) Operating Voltage: 4.5V-5.5V\r\nDC (VBUS Powered) Supply Current: 7mA (Max @1.5Mbps), 8mA (Max @12Mbps) ESD\r\nProtection: ±8kV (IEC 61000-4-2 Contact Discharge) CMTI: \u0026gt;25kV\/μs (Common-Mode\r\nTransient Immunity) Isolation Technology: ADI iCoupler Magnetic Coupling USB\r\nPorts: Type-A Female (Output), Type-B Female (Input) Operating Temperature:\r\n-40°C to +105°C Protection: Upstream Short-Circuit, Overvoltage Lockout\r\nCompliance: USB 2.0, RoHS, Automotive Grade 2. Pin Functions VBUS1: Input\r\nPower (4.5V-5.5V DC), Connects to Host VBUS GND1: Input Ground (Host Side\r\nReference) D+1\/D-1: Host-Side Data Lines (Bidirectional Differential Pair)\r\nVBUS2: Output Power (Isolated 5V DC), Connects to Peripheral VBUS GND2: Output\r\nGround (Peripheral Side Isolated Reference) D+2\/D-2: Peripheral-Side Data\r\nLines 3. Frequently Asked Questions Q1: Does this support USB 3.0 or high-\r\nspeed (480Mbps) devices? A1: No. Only USB 2.0 Low\/Full Speed (1.5Mbps\/12Mbps)\r\ndevices are compatible (e.g., keyboards, mice, serial adapters) . Q2: Can it\r\nbe hot-plugged during operation? A2: Yes. Supports USB hot-swapping without\r\nhost reboot. Ensure input voltage (VBUS1) is stable before peripheral\r\nconnection . Q3: Why does my PC fail to detect the peripheral after\r\ninstallation? A3: Check: ① VBUS1 voltage ≥4.5V (use regulated 5V power); ②\r\nPeripheral draws \u0026lt;100mA current (isolator max output: 180mA); ③ No pin\r\nmisalignment (GND1\/GND2 must be correctly referenced) .\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eHigh-Voltage Isolation2500V RMS isolation; UL 1577 certified; protects against electrical surges and short circuits\u003c\/li\u003e\r\n \u003cli\u003eFast and Reliable Data TransferSupports USB 2.0 low\/full speed (1.5Mbps\/12Mbps); 8mA max supply current at 12Mbps\u003c\/li\u003e\r\n \u003cli\u003eRobust ESD Protection8kV contact discharge protection; \u0026gt;25kV\/s common-mode transient immunity for stable operation\u003c\/li\u003e\r\n \u003cli\u003eWide Operating Temperature Range-40C to +105C; suitable for industrial Enviro nments and outdoor applications\u003c\/li\u003e\r\n \u003cli\u003eEasy Integration and CompatibilityWorks with USB 2.0 peripherals; hot-swappable without system reboot; 5V isolated output for peripheral power\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
