{"id":7991581573300,"title":"TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH","handle":"tecnoiot-1pc-usb-logic-analyzer-24mhz-8ch-8ch-debugger-for-arm-fpga-24m-8ch","description":"\u003ch3\u003eTECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eUSB Logic Analyzer Device Set USB Cable 24MHz 8 Channel 24MHz For ARM FPGA\nM100 Descriptions: Sampling rate up to: 24 MHz, can be 24 MHz. 16MHz, 12MHz,\n8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz; The\nlogic for each channel sampling rate of 24M\/s. General applications around\n10M, enough to cope with a variety of occasions; 8-channel. Voltage range:\nInput voltage range: -0.5V to 5.25V Input Low Voltage: -0.5V to 0.8V Input\nhigh voltage: 2.0V to 5.25V. Works with 5V, 3.3V, 2.5V, 2.0V systems. May work\nwith 1.8V but not recommended. Input impedance: 1Mohm || 10pF (typical,\napproximate) Crystal: +\/-20ppm, 24MHz. Error\/Accuracy: pulse-width\nmeasurement: +\/- 42ns (at 24MHz) Package includes: 1 x analyser device. 1 x\nUSB cable. Free Dupont Line\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eUSB Logic AnalyzerUSB Logic Analyzer Device Kit, 24MHz, 8 Channels, 24MHz USB Cable for ARM FPGA M100.\u003c\/li\u003e\n \u003cli\u003eCompact Design Sampling rate up to: 24MHz, can be 16MHz, 12MHz, 8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz; The logic for each channel has a sampling rate of 24 M\/s. General applications: approx. 10 million, enough for a variety of occasions; 8 channels;\u003c\/li\u003e\n \u003cli\u003eVoltage RangeInput voltage range: -0.5V to 5.25V; Low input voltage: -0.5V to 0.8V; High input voltage: 2.0V to 5.25V\u003c\/li\u003e\n \u003cli\u003eHigh performance: works with 5V, 3.3V, 2.5V and 2.0V systems. It can work with 1.8V, but is not recommended. Input impedance: 1 MOhm || 10 pF (typical, approximate); Quartz: +\/-20 ppm, 24 MHz; error\/accuracy: pulse width measurement: +\/- 42 ns (at 24 MHz)\u003c\/li\u003e\n \u003cli\u003ePackage includes: 1 x analyzer - 1 x Dupont line without USB cable\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-09-23T00:37:43+10:00","created_at":"2025-09-23T00:37:40+10:00","vendor":"TECNOIOT","type":"Logic Analysers","tags":["industryDE_Sep2025"],"price":12100,"price_min":12100,"price_max":12100,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44047755935924,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B0D2D71W9C","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH","public_title":null,"options":["Default Title"],"price":12100,"weight":46,"compare_at_price":null,"inventory_management":"shopify","barcode":"A850-USBLogicAnalyzer-291-1PCS","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/de-B0D2D71W9C.jpg?v=1775768003","\/\/auspowers.com\/cdn\/shop\/files\/51TNrHHT8jL.jpg?v=1758551862","\/\/auspowers.com\/cdn\/shop\/files\/519J8RMiaCL.jpg?v=1758551862","\/\/auspowers.com\/cdn\/shop\/files\/415BvDE2O0L.jpg?v=1758551862","\/\/auspowers.com\/cdn\/shop\/files\/4102ij19DML.jpg?v=1758551862","\/\/auspowers.com\/cdn\/shop\/files\/41gZrBiYA5L.jpg?v=1758551862","\/\/auspowers.com\/cdn\/shop\/files\/41CfNqmuGxL.jpg?v=1758551862"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/de-B0D2D71W9C.jpg?v=1775768003","options":["Title"],"media":[{"alt":"[Australia - AusPower] - TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH ","id":32184651088052,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/de-B0D2D71W9C.jpg?v=1775768003"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/de-B0D2D71W9C.jpg?v=1775768003","width":1000},{"alt":"[Australia - AusPower] - TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH ","id":32184651120820,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/51TNrHHT8jL.jpg?v=1758551862"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/51TNrHHT8jL.jpg?v=1758551862","width":1000},{"alt":"[Australia - AusPower] - TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH ","id":32184651153588,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/519J8RMiaCL.jpg?v=1758551862"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/519J8RMiaCL.jpg?v=1758551862","width":1000},{"alt":"[Australia - AusPower] - TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH ","id":32184651186356,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/415BvDE2O0L.jpg?v=1758551862"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/415BvDE2O0L.jpg?v=1758551862","width":1000},{"alt":"[Australia - AusPower] - TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH ","id":32184651219124,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/4102ij19DML.jpg?v=1758551862"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/4102ij19DML.jpg?v=1758551862","width":1000},{"alt":"[Australia - AusPower] - TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH ","id":32184651251892,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/41gZrBiYA5L.jpg?v=1758551862"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/41gZrBiYA5L.jpg?v=1758551862","width":1000},{"alt":"[Australia - AusPower] - TECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH ","id":32184651284660,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/41CfNqmuGxL.jpg?v=1758551862"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/41CfNqmuGxL.jpg?v=1758551862","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eTECNOIOT 1PC USB Logic Analyzer 24MHz 8CH 8CH Debugger for ARM FPGA 24M 8CH\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eUSB Logic Analyzer Device Set USB Cable 24MHz 8 Channel 24MHz For ARM FPGA\nM100 Descriptions: Sampling rate up to: 24 MHz, can be 24 MHz. 16MHz, 12MHz,\n8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz; The\nlogic for each channel sampling rate of 24M\/s. General applications around\n10M, enough to cope with a variety of occasions; 8-channel. Voltage range:\nInput voltage range: -0.5V to 5.25V Input Low Voltage: -0.5V to 0.8V Input\nhigh voltage: 2.0V to 5.25V. Works with 5V, 3.3V, 2.5V, 2.0V systems. May work\nwith 1.8V but not recommended. Input impedance: 1Mohm || 10pF (typical,\napproximate) Crystal: +\/-20ppm, 24MHz. Error\/Accuracy: pulse-width\nmeasurement: +\/- 42ns (at 24MHz) Package includes: 1 x analyser device. 1 x\nUSB cable. Free Dupont Line\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eUSB Logic AnalyzerUSB Logic Analyzer Device Kit, 24MHz, 8 Channels, 24MHz USB Cable for ARM FPGA M100.\u003c\/li\u003e\n \u003cli\u003eCompact Design Sampling rate up to: 24MHz, can be 16MHz, 12MHz, 8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz; The logic for each channel has a sampling rate of 24 M\/s. General applications: approx. 10 million, enough for a variety of occasions; 8 channels;\u003c\/li\u003e\n \u003cli\u003eVoltage RangeInput voltage range: -0.5V to 5.25V; Low input voltage: -0.5V to 0.8V; High input voltage: 2.0V to 5.25V\u003c\/li\u003e\n \u003cli\u003eHigh performance: works with 5V, 3.3V, 2.5V and 2.0V systems. It can work with 1.8V, but is not recommended. Input impedance: 1 MOhm || 10 pF (typical, approximate); Quartz: +\/-20 ppm, 24 MHz; error\/accuracy: pulse width measurement: +\/- 42 ns (at 24 MHz)\u003c\/li\u003e\n \u003cli\u003ePackage includes: 1 x analyzer - 1 x Dupont line without USB cable\u003c\/li\u003e\n \u003c\/ul\u003e"}
