{"id":7358528651444,"title":"Taidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover) 2K Ohm","handle":"taidacent-ohm-meter-resistance-tester-ohmmeter-digital-dc-resistance-measuring-instrument-fixture-resistance-measure-panel-meter-2k-ohm-dc12v-with-cover-2k-ohm","description":"\u003ch3\u003eTaidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover)\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eParameter Power supply: DC5V\/DC12V optional (current consumption is less than\n50mA) Display range: -1999 ~ 1999 Font size: 0.56 inches red LED Measurement\naccuracy: 0.5 level ± 2 words Temperature drift coefficient: less than\n100PPM\/C Working environment: 0-50%?; 80%RH Dimensions: 79x43x28mm Hole size:\n76x39.5mm (±0.5~1mm) Package type: flat right-angle frame, purple frosted\nwindow Resistance Range: 200? Display range: 0- 199.9 Resolution: 100m? Input\nimpedance: 200? Range: 2K? Display range: 0- 1.999 Resolution: 1? Input\nimpedance: 2K? Range: 20K? Display range: 0- 19.99 Resolution: 10? Input\nimpedance: 20K? Range: 200K? Display range: 0- 199.9 Resolution: 100? Input\nimpedance: 200K? Above 200?, within 2K?, please select 2K? range, resolution\nis 1? Above 2K?, within 20K?, please select 20K? range, resolution is 10?\nAbove 20K?, within 200K?, please select 200K? range, resolution is 100?\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003ePower supply: DC5V\/DC12V optional (current consumption is less than 50mA)\u003c\/li\u003e\n \u003cli\u003eThis ohmmeter is a common ground instrument, non-isolated, it is recommended to use a separate power supply, that is, the power supply is not related to the signal\u003c\/li\u003e\n \u003cli\u003eThe resistance meter cannot be measured with electricity, otherwise the meter will be burnt out\u003c\/li\u003e\n \u003cli\u003eSelect a suitable range, if the range is selected too much, the small resistance cannot be recognized or the measurement is inaccurate\u003c\/li\u003e\n \u003cli\u003eThe meter head is a common ground instrument (that is, the negative pole of the power supply and the negative pole of the signal are connected), it is recommended to use a separate, independent, and isolated power supply (that is, the power supply and the measurement terminal are not related)\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2023-03-01T20:18:46+11:00","created_at":"2023-03-01T20:18:52+11:00","vendor":"Taidacent","type":"","tags":["industrial_Dec2022"],"price":15000,"price_min":15000,"price_max":15000,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42195217678516,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B09JBHYQ6D","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Taidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover) 2K Ohm","public_title":null,"options":["Default Title"],"price":15000,"weight":50,"compare_at_price":null,"inventory_management":null,"barcode":"738190911935","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/products\/B09JBHYQ6D.jpg?v=1677740097","\/\/auspowers.com\/cdn\/shop\/products\/512Kk6ujORL_3f97b374-7763-43ef-b7a6-9a3842a593b1.jpg?v=1677662332","\/\/auspowers.com\/cdn\/shop\/products\/51vHXckBlUL_22e92538-a0e7-4ef3-866d-e202ad26366d.jpg?v=1677662332","\/\/auspowers.com\/cdn\/shop\/products\/41IguUtlmmL_1974199d-8e24-475c-a7e5-4aed04a31a2d.jpg?v=1677662332","\/\/auspowers.com\/cdn\/shop\/products\/419kvbSlFjL_ce4b8881-b2ef-43ef-8dc1-cc74c0909a4a.jpg?v=1677662332"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/products\/B09JBHYQ6D.jpg?v=1677740097","options":["Title"],"media":[{"alt":"[Australia - AusPower] - Taidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover) 2K Ohm ","id":28314899284148,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/products\/B09JBHYQ6D.jpg?v=1677740097"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/B09JBHYQ6D.jpg?v=1677740097","width":1000},{"alt":"[Australia - AusPower] - Taidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover) 2K Ohm ","id":28310615228596,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/auspowers.com\/cdn\/shop\/products\/512Kk6ujORL_3f97b374-7763-43ef-b7a6-9a3842a593b1.jpg?v=1677662332"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/512Kk6ujORL_3f97b374-7763-43ef-b7a6-9a3842a593b1.jpg?v=1677662332","width":1001},{"alt":"[Australia - AusPower] - Taidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover) 2K Ohm ","id":28310615261364,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/auspowers.com\/cdn\/shop\/products\/51vHXckBlUL_22e92538-a0e7-4ef3-866d-e202ad26366d.jpg?v=1677662332"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/51vHXckBlUL_22e92538-a0e7-4ef3-866d-e202ad26366d.jpg?v=1677662332","width":1001},{"alt":"[Australia - AusPower] - Taidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover) 2K Ohm ","id":28310615294132,"position":4,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/products\/41IguUtlmmL_1974199d-8e24-475c-a7e5-4aed04a31a2d.jpg?v=1677662332"},"aspect_ratio":1.0,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/41IguUtlmmL_1974199d-8e24-475c-a7e5-4aed04a31a2d.jpg?v=1677662332","width":500},{"alt":"[Australia - AusPower] - Taidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover) 2K Ohm ","id":28310615326900,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/products\/419kvbSlFjL_ce4b8881-b2ef-43ef-8dc1-cc74c0909a4a.jpg?v=1677662332"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/419kvbSlFjL_ce4b8881-b2ef-43ef-8dc1-cc74c0909a4a.jpg?v=1677662332","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eTaidacent Ohm Meter Resistance Tester Ohmmeter Digital DC Resistance Measuring Instrument Fixture Resistance Measure Panel Meter (2K Ohm, DC12V with Cover)\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eParameter Power supply: DC5V\/DC12V optional (current consumption is less than\n50mA) Display range: -1999 ~ 1999 Font size: 0.56 inches red LED Measurement\naccuracy: 0.5 level ± 2 words Temperature drift coefficient: less than\n100PPM\/C Working environment: 0-50%?; 80%RH Dimensions: 79x43x28mm Hole size:\n76x39.5mm (±0.5~1mm) Package type: flat right-angle frame, purple frosted\nwindow Resistance Range: 200? Display range: 0- 199.9 Resolution: 100m? Input\nimpedance: 200? Range: 2K? Display range: 0- 1.999 Resolution: 1? Input\nimpedance: 2K? Range: 20K? Display range: 0- 19.99 Resolution: 10? Input\nimpedance: 20K? Range: 200K? Display range: 0- 199.9 Resolution: 100? Input\nimpedance: 200K? Above 200?, within 2K?, please select 2K? range, resolution\nis 1? Above 2K?, within 20K?, please select 20K? range, resolution is 10?\nAbove 20K?, within 200K?, please select 200K? range, resolution is 100?\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003ePower supply: DC5V\/DC12V optional (current consumption is less than 50mA)\u003c\/li\u003e\n \u003cli\u003eThis ohmmeter is a common ground instrument, non-isolated, it is recommended to use a separate power supply, that is, the power supply is not related to the signal\u003c\/li\u003e\n \u003cli\u003eThe resistance meter cannot be measured with electricity, otherwise the meter will be burnt out\u003c\/li\u003e\n \u003cli\u003eSelect a suitable range, if the range is selected too much, the small resistance cannot be recognized or the measurement is inaccurate\u003c\/li\u003e\n \u003cli\u003eThe meter head is a common ground instrument (that is, the negative pole of the power supply and the negative pole of the signal are connected), it is recommended to use a separate, independent, and isolated power supply (that is, the power supply and the measurement terminal are not related)\u003c\/li\u003e\n \u003c\/ul\u003e"}
