STEPPERONLINE Nema 17 Stepper Motor Bipolar 40 Ncm 12 V 0.4 A 42 x 42 x 40 mm Reprap CNC Kit

In Stock. Leaves warehouse within 2 - 3 business days

$201.00 AUD
Maximum quantity available reached.
Start shopping today and enjoy free shipping on every purchase.
More detailed product descriptions
Free Shipping Australia Wide
100% Safe & Secure Checkout
100 Days Return Policy *
1 Year Warranty *

STEPPERONLINE Nema 17 Stepper Motor Bipolar 40 Ncm 12 V 0.4 A 42 x 42 x 40 mm Reprap CNC Kit

Electrical specification: Manufacturer Part Number: 17HS15-0404S Motor type: bipolar Step Angle: 1.8 degree Holding torque: 40 Ncm(56.6 oz.in)) Rated current/phase: 0.4 A. Phase resistance: 30 ohms Voltage: 12V Inductance: 58mH±20% (1KHz) Physical specification: Frame size: 42 x 42 mm. Body length: 39 mm. Shaft diameter: 5 mm. Shaft length: 24 mm. D-cut length: 15 mm. Number of leads: 4. Lead rotation: 500 mm. Weight: 290g Connection: Black (A +), Red (A-), Green (B +), Blue (B-). Warning: As a stepper motor, it should be connected to a constant current or chopper driver. If you connect the motor directly to a power supply, the motor will be destroyed. Please pay attention to order four wire coils when you connect to the driver, or it will damage your driver.

Product Features

  • This Bipolar Nema 17 stepper motor with step angle 1.8 deg and size 42 x 42 x 39 mm
  • It has 4 wires, each phase draws current 0.4 A at 12 V, with holding torque 40 Ncm (56.6 oz.in)
  • 100% brand new from "STEPPERONLINE" and ROHS and CE certified.
