{"id":7170100166836,"title":"RioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W","handle":"riorand-upgraded-adjustable-dc-motor-speed-pwm-controller-10v-12v-24v-30v-reversing-switch-120w","description":"\u003ch3\u003eRioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecifications: 1. Net weight: 70g 2. Size: 74 47 28（mm） 3. Model:\nRRCCM2SPC Main technical parameters: 1.Working Voltage: DC 10V - DC 30V\n2.Maximum power: 120W 3.Rated Current: 3A 4.Max Current: 4A 5.Maximum\ncontinuous output current:3A ;Overload short circuit protection current:4A\n,short circuit time does not exceed 30 seconds 6.PWM Frequency: 500 KHz 7.PWM\npulse width modulation range: 5% -95% 8.Motor Type:Brush What's in box: 1 x\nRioRand Adjustable DC Motor Speed Controller Attention: 1.Pls do not connect\nAC power directly(Such as:110V AC),the input volt of this controller should be\nDC,otherwise it will be burned out 2.Positive and negative pole of the POWER\ncan not be reversed 3.Positive and negative pole of the MOTOR can be\nreversed.When the direction of operation is inconsistent with your\nexpectations,you can change the direction by adjusting the order of the line\n4.Adjust the potentiometer knob to change output duty cycle\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMaximum continuous output current:3A ;Overload short circuit protection current:4A ,short circuit time does not exceed 30 seconds\u003c\/li\u003e\n \u003cli\u003eWorking Voltage:DC 10V - DC 30V;Maximum output power:120W\u003c\/li\u003e\n \u003cli\u003ePWM Frequency: 500 KHz;PWM Pulse Width Modulation Range: 5% -95%\u003c\/li\u003e\n \u003cli\u003eApplicable Motor:brush motor\u003c\/li\u003e\n \u003cli\u003ePlease note that this controller has a low frequency causing some types of the motor to whine at low speeds but not all motors will be like this\u003c\/li\u003e\n \u003c\/ul\u003e\n\n","published_at":"2022-06-26T21:05:47+10:00","created_at":"2022-06-26T21:05:53+10:00","vendor":"RioRand","type":"Motor Speed Controllers","tags":["industrial"],"price":11800,"price_min":11800,"price_max":11800,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":41609738879156,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B00HTZD9YI","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"RioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W","public_title":null,"options":["Default Title"],"price":11800,"weight":82,"compare_at_price":null,"inventory_management":null,"barcode":"619636103209","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/products\/B00HTZD9YI.jpg?v=1656315962","\/\/auspowers.com\/cdn\/shop\/products\/61NoEdaeSDL.jpg?v=1656241553","\/\/auspowers.com\/cdn\/shop\/products\/41kyIr32SHL.jpg?v=1656241553","\/\/auspowers.com\/cdn\/shop\/products\/61nkFSEH03L.jpg?v=1656241553","\/\/auspowers.com\/cdn\/shop\/products\/61l0HFvZ1nL.jpg?v=1656241553","\/\/auspowers.com\/cdn\/shop\/products\/61sKkv5DoTL.jpg?v=1656241553"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/products\/B00HTZD9YI.jpg?v=1656315962","options":["Title"],"media":[{"alt":"[Australia - AusPower] - RioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W ","id":26305322549428,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/auspowers.com\/cdn\/shop\/products\/B00HTZD9YI.jpg?v=1656315962"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/B00HTZD9YI.jpg?v=1656315962","width":1001},{"alt":"[Australia - AusPower] - RioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W ","id":26296278876340,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/auspowers.com\/cdn\/shop\/products\/61NoEdaeSDL.jpg?v=1656241553"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/61NoEdaeSDL.jpg?v=1656241553","width":1001},{"alt":"[Australia - AusPower] - RioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W ","id":26296278909108,"position":3,"preview_image":{"aspect_ratio":1.404,"height":356,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/products\/41kyIr32SHL.jpg?v=1656241553"},"aspect_ratio":1.404,"height":356,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/41kyIr32SHL.jpg?v=1656241553","width":500},{"alt":"[Australia - AusPower] - RioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W ","id":26296278941876,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/auspowers.com\/cdn\/shop\/products\/61nkFSEH03L.jpg?v=1656241553"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/61nkFSEH03L.jpg?v=1656241553","width":1001},{"alt":"[Australia - AusPower] - RioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W ","id":26296279007412,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/auspowers.com\/cdn\/shop\/products\/61l0HFvZ1nL.jpg?v=1656241553"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/61l0HFvZ1nL.jpg?v=1656241553","width":1001},{"alt":"[Australia - AusPower] - RioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W ","id":26296279040180,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/auspowers.com\/cdn\/shop\/products\/61sKkv5DoTL.jpg?v=1656241553"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/products\/61sKkv5DoTL.jpg?v=1656241553","width":1001}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eRioRand Upgraded Adjustable DC Motor Speed PWM Controller 10V 12V 24V 30V Reversing Switch 120W\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecifications: 1. Net weight: 70g 2. Size: 74 47 28（mm） 3. Model:\nRRCCM2SPC Main technical parameters: 1.Working Voltage: DC 10V - DC 30V\n2.Maximum power: 120W 3.Rated Current: 3A 4.Max Current: 4A 5.Maximum\ncontinuous output current:3A ;Overload short circuit protection current:4A\n,short circuit time does not exceed 30 seconds 6.PWM Frequency: 500 KHz 7.PWM\npulse width modulation range: 5% -95% 8.Motor Type:Brush What's in box: 1 x\nRioRand Adjustable DC Motor Speed Controller Attention: 1.Pls do not connect\nAC power directly(Such as:110V AC),the input volt of this controller should be\nDC,otherwise it will be burned out 2.Positive and negative pole of the POWER\ncan not be reversed 3.Positive and negative pole of the MOTOR can be\nreversed.When the direction of operation is inconsistent with your\nexpectations,you can change the direction by adjusting the order of the line\n4.Adjust the potentiometer knob to change output duty cycle\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMaximum continuous output current:3A ;Overload short circuit protection current:4A ,short circuit time does not exceed 30 seconds\u003c\/li\u003e\n \u003cli\u003eWorking Voltage:DC 10V - DC 30V;Maximum output power:120W\u003c\/li\u003e\n \u003cli\u003ePWM Frequency: 500 KHz;PWM Pulse Width Modulation Range: 5% -95%\u003c\/li\u003e\n \u003cli\u003eApplicable Motor:brush motor\u003c\/li\u003e\n \u003cli\u003ePlease note that this controller has a low frequency causing some types of the motor to whine at low speeds but not all motors will be like this\u003c\/li\u003e\n \u003c\/ul\u003e\n\n"}
