{"id":8012770476212,"title":"Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm","handle":"heschen-photoelectric-sensor-switch-e3jk-ds30m1-dc12-24v-diffuse-type-detection-distance-30cm","description":"\u003ch3\u003eHeschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eCharacteristic parameters: Respnose time: 30msConnectin delay:1.5msSupply\r\nvoltage:DC type: DC12-24V(6-36V) Impulse(p-p) 10% belowLight source: Infrared\r\nlight 660nmPower current: 3V belowControl output: 2A below(contact service\r\nlife: 0.1 million times)Impulsion and vibration are allowed: B\u0026lt;30g,T\u0026lt;11ms,\r\nf\u0026lt;55Hz, a\u0026lt;1mmInsulation impedance: 50Mohm above between charging part and\r\nhousingWithstand voltage: AC1000V 50\/60Hz 1min between charging part and\r\nhousingTemperature Influence : Temperature range-30～＋65℃,at + 23℃,± 15%\r\ndetection distance; Temperature range-25～＋60℃, at +23℃, ±10% detection\r\ndistanceVoltage influence: Inside ±15% rated supply voltage range, at rated\r\nsupply voltage value, inside ±10% detection distance.Protection structure:\r\nIP65(IEC specification)Material: Housing: Nickel plated brass(ABS) Detection\r\nsurface(lens): PMMA\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eSupply Voltage: 12-24VDC; Load Rating: 3A 250VAC\u003c\/li\u003e\r\n \u003cli\u003eDetection Range: 30cm 10%; Detection Range Regulation: Sensitivity Adjuster\u003c\/li\u003e\r\n \u003cli\u003eRelay output: DC illuminate\u003c\/li\u003e\r\n \u003cli\u003eDetection Target: Transparent\/Opaque Object\u003c\/li\u003e\r\n \u003cli\u003eDetection Method: Diffuse Type\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-12-05T17:08:42+11:00","created_at":"2025-12-05T17:08:39+11:00","vendor":"Heschen","type":"Photoelectric Sensors","tags":["industrial_selected_Nov2025"],"price":13100,"price_min":13100,"price_max":13100,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44101733023924,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0712143QP","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm","public_title":null,"options":["Default Title"],"price":13100,"weight":200,"compare_at_price":null,"inventory_management":"shopify","barcode":"670534170212","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/B0712143QP.jpg?v=1775778621","\/\/auspowers.com\/cdn\/shop\/files\/511XrE46bBL.jpg?v=1764914921","\/\/auspowers.com\/cdn\/shop\/files\/51Z2UixlsqL.jpg?v=1764914921","\/\/auspowers.com\/cdn\/shop\/files\/51nlvMaK2-L_0346042a-fccb-4bf2-bc46-b609df204ac6.jpg?v=1764914921","\/\/auspowers.com\/cdn\/shop\/files\/515JRNiX9JL.jpg?v=1764914922","\/\/auspowers.com\/cdn\/shop\/files\/61QOFeqcFoL_2e03806f-166b-4b71-a057-25373f046c43.jpg?v=1764914921","\/\/auspowers.com\/cdn\/shop\/files\/71ybV5szT0L_ef46a3f6-f531-4282-8fac-ce472885f7d8.jpg?v=1764914921"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/B0712143QP.jpg?v=1775778621","options":["Title"],"media":[{"alt":"[Australia - AusPower] - Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm ","id":32445928145076,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/auspowers.com\/cdn\/shop\/files\/B0712143QP.jpg?v=1775778621"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/B0712143QP.jpg?v=1775778621","width":1200},{"alt":"[Australia - AusPower] - Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm ","id":32445928177844,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/auspowers.com\/cdn\/shop\/files\/511XrE46bBL.jpg?v=1764914921"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/511XrE46bBL.jpg?v=1764914921","width":1200},{"alt":"[Australia - AusPower] - Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm ","id":32445928210612,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/auspowers.com\/cdn\/shop\/files\/51Z2UixlsqL.jpg?v=1764914921"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/51Z2UixlsqL.jpg?v=1764914921","width":1200},{"alt":"[Australia - AusPower] - Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm ","id":32445928243380,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/auspowers.com\/cdn\/shop\/files\/51nlvMaK2-L_0346042a-fccb-4bf2-bc46-b609df204ac6.jpg?v=1764914921"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/51nlvMaK2-L_0346042a-fccb-4bf2-bc46-b609df204ac6.jpg?v=1764914921","width":1300},{"alt":"[Australia - AusPower] - Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm ","id":32445928276148,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/auspowers.com\/cdn\/shop\/files\/515JRNiX9JL.jpg?v=1764914922"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/515JRNiX9JL.jpg?v=1764914922","width":1200},{"alt":"[Australia - AusPower] - Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm ","id":32445928308916,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61QOFeqcFoL_2e03806f-166b-4b71-a057-25373f046c43.jpg?v=1764914921"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61QOFeqcFoL_2e03806f-166b-4b71-a057-25373f046c43.jpg?v=1764914921","width":1300},{"alt":"[Australia - AusPower] - Heschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm ","id":32445928341684,"position":7,"preview_image":{"aspect_ratio":0.75,"height":1702,"width":1276,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71ybV5szT0L_ef46a3f6-f531-4282-8fac-ce472885f7d8.jpg?v=1764914921"},"aspect_ratio":0.75,"height":1702,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71ybV5szT0L_ef46a3f6-f531-4282-8fac-ce472885f7d8.jpg?v=1764914921","width":1276}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHeschen Photoelectric Sensor Switch E3JK-DS30M1 DC12-24V Diffuse Type Detection Distance 30cm\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eCharacteristic parameters: Respnose time: 30msConnectin delay:1.5msSupply\r\nvoltage:DC type: DC12-24V(6-36V) Impulse(p-p) 10% belowLight source: Infrared\r\nlight 660nmPower current: 3V belowControl output: 2A below(contact service\r\nlife: 0.1 million times)Impulsion and vibration are allowed: B\u0026lt;30g,T\u0026lt;11ms,\r\nf\u0026lt;55Hz, a\u0026lt;1mmInsulation impedance: 50Mohm above between charging part and\r\nhousingWithstand voltage: AC1000V 50\/60Hz 1min between charging part and\r\nhousingTemperature Influence : Temperature range-30～＋65℃,at + 23℃,± 15%\r\ndetection distance; Temperature range-25～＋60℃, at +23℃, ±10% detection\r\ndistanceVoltage influence: Inside ±15% rated supply voltage range, at rated\r\nsupply voltage value, inside ±10% detection distance.Protection structure:\r\nIP65(IEC specification)Material: Housing: Nickel plated brass(ABS) Detection\r\nsurface(lens): PMMA\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eSupply Voltage: 12-24VDC; Load Rating: 3A 250VAC\u003c\/li\u003e\r\n \u003cli\u003eDetection Range: 30cm 10%; Detection Range Regulation: Sensitivity Adjuster\u003c\/li\u003e\r\n \u003cli\u003eRelay output: DC illuminate\u003c\/li\u003e\r\n \u003cli\u003eDetection Target: Transparent\/Opaque Object\u003c\/li\u003e\r\n \u003cli\u003eDetection Method: Diffuse Type\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
