{"id":8013438943412,"title":"Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire","handle":"heschen-m18-column-infrared-photoelectric-proximity-switch-diffuse-reflection-type-e3f-ds200c3-detection-distance-10-200cm-10-30vdc-200ma-npn-no-nc-4-wire","description":"\u003ch3\u003eHeschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eConnection Delay: 1.5ms.Light Source: Infrared light 660nm.Supply Voltage:\r\nDC10-30V Impulse (p-p)10% below.Comsuption Current: 20mA below.Control Output:\r\n200mA below.Loop Protection: Reversal connection protection,surge\r\nabsorption,load short-circuit protection.Ambient Temperature \u0026amp; Humidity:\r\nDuring operation, Storage: individually-30～＋65℃(no freeze ,no drew ), During\r\noperation, Storage: Individually 35-95%RH.Insulation Impedance: 50MΩ above (\r\nDC500 megameter ) between charging part and housing.Withstand Voltage: AC1000V\r\n50\/60Hz 1min between charging part and housing.Temperature Influence:\r\nTemperature range-30～＋65℃,at + 23℃,± 15% detection distance, Temperature\r\nrange-25～＋60℃,at +23℃,±10% detection distance.Voltage Influence: Inside ±15%\r\nrated supply voltage range, at rated supply voltage value ,inside ± 10 %\r\ndetection distance.\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eMounting Hole Diameter: 18mm; Cable Length: 150cm\/59\"\u003c\/li\u003e\r\n \u003cli\u003eDetecting Distance: 10-200cm10%, Adjustable\u003c\/li\u003e\r\n \u003cli\u003eOutput Type: NPN NO+NC; Diffuse Reflection Type\u003c\/li\u003e\r\n \u003cli\u003eCurrent Output: 200mA; Working Voltage: 10-30VDC\u003c\/li\u003e\r\n \u003cli\u003eDetection Terget: Opaque Object\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-12-09T01:56:29+11:00","created_at":"2025-12-09T01:56:25+11:00","vendor":"Heschen","type":"Inductive","tags":["industrial_selected_Nov2025"],"price":10000,"price_min":10000,"price_max":10000,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44103309131956,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0B1WPRWBS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire","public_title":null,"options":["Default Title"],"price":10000,"weight":60,"compare_at_price":null,"inventory_management":"shopify","barcode":"HS-E3F-DS200C3","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/B0B1WPRWBS.jpg?v=1775783571","\/\/auspowers.com\/cdn\/shop\/files\/61Gb10KyqnL.jpg?v=1765205788","\/\/auspowers.com\/cdn\/shop\/files\/51ITKi6qUdL.jpg?v=1765205788","\/\/auspowers.com\/cdn\/shop\/files\/61MpTVKYXkL.jpg?v=1765205788","\/\/auspowers.com\/cdn\/shop\/files\/61RURXOb2lL.jpg?v=1765205788","\/\/auspowers.com\/cdn\/shop\/files\/51CJzA15jxL.jpg?v=1765205788","\/\/auspowers.com\/cdn\/shop\/files\/71yjGAgdD1L_2f9455ff-4f97-4fab-9b1d-ad09ea628759.jpg?v=1765205788"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/B0B1WPRWBS.jpg?v=1775783571","options":["Title"],"media":[{"alt":"[Australia - AusPower] - Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire ","id":32455615086772,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/auspowers.com\/cdn\/shop\/files\/B0B1WPRWBS.jpg?v=1775783571"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/B0B1WPRWBS.jpg?v=1775783571","width":1300},{"alt":"[Australia - AusPower] - Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire ","id":32455615119540,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61Gb10KyqnL.jpg?v=1765205788"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61Gb10KyqnL.jpg?v=1765205788","width":1300},{"alt":"[Australia - AusPower] - Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire ","id":32455615152308,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/auspowers.com\/cdn\/shop\/files\/51ITKi6qUdL.jpg?v=1765205788"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/51ITKi6qUdL.jpg?v=1765205788","width":1300},{"alt":"[Australia - AusPower] - Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire ","id":32455615185076,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61MpTVKYXkL.jpg?v=1765205788"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61MpTVKYXkL.jpg?v=1765205788","width":1300},{"alt":"[Australia - AusPower] - Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire ","id":32455615217844,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61RURXOb2lL.jpg?v=1765205788"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61RURXOb2lL.jpg?v=1765205788","width":1300},{"alt":"[Australia - AusPower] - Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire ","id":32455615250612,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/auspowers.com\/cdn\/shop\/files\/51CJzA15jxL.jpg?v=1765205788"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/51CJzA15jxL.jpg?v=1765205788","width":1300},{"alt":"[Australia - AusPower] - Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire ","id":32455615283380,"position":7,"preview_image":{"aspect_ratio":0.75,"height":1702,"width":1276,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71yjGAgdD1L_2f9455ff-4f97-4fab-9b1d-ad09ea628759.jpg?v=1765205788"},"aspect_ratio":0.75,"height":1702,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71yjGAgdD1L_2f9455ff-4f97-4fab-9b1d-ad09ea628759.jpg?v=1765205788","width":1276}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHeschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS200C3, Detection Distance 10-200CM, 10-30VDC 200mA, NPN NO+NC, 4 Wire\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eConnection Delay: 1.5ms.Light Source: Infrared light 660nm.Supply Voltage:\r\nDC10-30V Impulse (p-p)10% below.Comsuption Current: 20mA below.Control Output:\r\n200mA below.Loop Protection: Reversal connection protection,surge\r\nabsorption,load short-circuit protection.Ambient Temperature \u0026amp; Humidity:\r\nDuring operation, Storage: individually-30～＋65℃(no freeze ,no drew ), During\r\noperation, Storage: Individually 35-95%RH.Insulation Impedance: 50MΩ above (\r\nDC500 megameter ) between charging part and housing.Withstand Voltage: AC1000V\r\n50\/60Hz 1min between charging part and housing.Temperature Influence:\r\nTemperature range-30～＋65℃,at + 23℃,± 15% detection distance, Temperature\r\nrange-25～＋60℃,at +23℃,±10% detection distance.Voltage Influence: Inside ±15%\r\nrated supply voltage range, at rated supply voltage value ,inside ± 10 %\r\ndetection distance.\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eMounting Hole Diameter: 18mm; Cable Length: 150cm\/59\"\u003c\/li\u003e\r\n \u003cli\u003eDetecting Distance: 10-200cm10%, Adjustable\u003c\/li\u003e\r\n \u003cli\u003eOutput Type: NPN NO+NC; Diffuse Reflection Type\u003c\/li\u003e\r\n \u003cli\u003eCurrent Output: 200mA; Working Voltage: 10-30VDC\u003c\/li\u003e\r\n \u003cli\u003eDetection Terget: Opaque Object\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
