{"id":8013433536692,"title":"Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor","handle":"garosa-cdd-11n-10mm-infrared-proximity-sensors-cylindrical-diffuse-reflection-photoelectric-npn-no-4-wire-12-24vdc-300ma-sensor","description":"\u003ch3\u003eGarosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eSpecification: Model: CDD-11N Power Supply Voltage: DC12-24V Output Form \u0026amp;\r\nStatus: NPN NO Detection Distance: 10mm Detecting Objects: Opaque objects\r\nCylindrical Head Diameter: 18mm Line Length: 1.75m Light Source Type:\r\nTransmitting tube Induction Method: Diffuse reflection Level: IP66 Housing\r\nMaterial: Copper plating Control Output: \u0026lt;300mA Current Consumption: \u0026lt;10mA\r\nResponse Frequency: 500Hz Voltage: \u0026lt;1.5V Indicator Light: Action indicator\r\n(red LED) Insulation Resistance: \u0026gt;50M? (500VDC megohm reference) Withstand\r\nVoltage: 1500VAC 50\/60Hz 1min Vibration Resistance: 10-55Hz (cycle one minute)\r\namplitude 1mm X, Y, Z 2 hours in each direction Impact Resistance: 500m\/s²\r\n(50G) X, Y, Z 3 times in all directions Operating Environment: -25~+70°C,\r\n35-95%RH Storage Environment: -30~+80°C, 35-95%RH Circuit: Built-in Circuit,\r\nPower Reverse Polarity Circuit, Over Current Circuit Package List: 1 x\r\nPhotoelectric\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eWORKING PRINCIPLE:Photoelectric switch makes use of the block or reflection of the detected object to the light beam, and the circuit is turned on by the synchronous circuit to detect the or absence of the object.\u003c\/li\u003e\r\n \u003cli\u003eWORKING PROCESS:The photoelectric switch converts the input current into a light on the transmitter, and the receiver detects the target object according to the or of the received light.\u003c\/li\u003e\r\n \u003cli\u003eHIGH SENSITIVITY:The sensor uses infrared light to detect the objects for sensitive detection with delay that can be almost ignored.\u003c\/li\u003e\r\n \u003cli\u003eWIDE RANGE OF USES:The detection objects of this photoelectric are not limited to metal, and all objects that reflect light (or block light) can be detected.\u003c\/li\u003e\r\n \u003cli\u003eSAFETY DESIGN:The photoelectric switch converts has built-in multiple circuits to ensure use.\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-12-09T01:46:08+11:00","created_at":"2025-12-09T01:46:05+11:00","vendor":"Garosa","type":"Photoelectric Sensors","tags":["industrial_selected_Nov2025"],"price":12800,"price_min":12800,"price_max":12800,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44103298384052,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B07WZD47ZM","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor","public_title":null,"options":["Default Title"],"price":12800,"weight":67,"compare_at_price":null,"inventory_management":"shopify","barcode":"739551845562","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/B07WZD47ZM.jpg?v=1775783286","\/\/auspowers.com\/cdn\/shop\/files\/71Zuq1JlJoL.jpg?v=1765205168","\/\/auspowers.com\/cdn\/shop\/files\/6151DCic_xL.jpg?v=1765205168","\/\/auspowers.com\/cdn\/shop\/files\/61bcX3BvQyL.jpg?v=1765205167","\/\/auspowers.com\/cdn\/shop\/files\/61U3YDj8atL.jpg?v=1765205168","\/\/auspowers.com\/cdn\/shop\/files\/71RL04vD_-L.jpg?v=1765205168","\/\/auspowers.com\/cdn\/shop\/files\/51VkjNt0-aL.jpg?v=1765205167","\/\/auspowers.com\/cdn\/shop\/files\/513ReHFLaeL.jpg?v=1765205167"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/B07WZD47ZM.jpg?v=1775783286","options":["Title"],"media":[{"alt":"[Australia - AusPower] - Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor ","id":32455578615988,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/B07WZD47ZM.jpg?v=1775783286"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/B07WZD47ZM.jpg?v=1775783286","width":1601},{"alt":"[Australia - AusPower] - Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor ","id":32455578648756,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71Zuq1JlJoL.jpg?v=1765205168"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71Zuq1JlJoL.jpg?v=1765205168","width":1601},{"alt":"[Australia - AusPower] - Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor ","id":32455578681524,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/6151DCic_xL.jpg?v=1765205168"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/6151DCic_xL.jpg?v=1765205168","width":1601},{"alt":"[Australia - AusPower] - Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor ","id":32455578714292,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61bcX3BvQyL.jpg?v=1765205167"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61bcX3BvQyL.jpg?v=1765205167","width":1601},{"alt":"[Australia - AusPower] - Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor ","id":32455578747060,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61U3YDj8atL.jpg?v=1765205168"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61U3YDj8atL.jpg?v=1765205168","width":1601},{"alt":"[Australia - AusPower] - Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor ","id":32455578779828,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71RL04vD_-L.jpg?v=1765205168"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71RL04vD_-L.jpg?v=1765205168","width":1601},{"alt":"[Australia - AusPower] - Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor ","id":32455578812596,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/51VkjNt0-aL.jpg?v=1765205167"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/51VkjNt0-aL.jpg?v=1765205167","width":1601},{"alt":"[Australia - AusPower] - Garosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor ","id":32455578845364,"position":8,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/513ReHFLaeL.jpg?v=1765205167"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/513ReHFLaeL.jpg?v=1765205167","width":1601}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eGarosa CDD-11N 10mm Infrared Proximity Sensors, Cylindrical Diffuse Reflection Photoelectric NPN NO 4-Wire 12-24VDC 300mA, Sensor\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eSpecification: Model: CDD-11N Power Supply Voltage: DC12-24V Output Form \u0026amp;\r\nStatus: NPN NO Detection Distance: 10mm Detecting Objects: Opaque objects\r\nCylindrical Head Diameter: 18mm Line Length: 1.75m Light Source Type:\r\nTransmitting tube Induction Method: Diffuse reflection Level: IP66 Housing\r\nMaterial: Copper plating Control Output: \u0026lt;300mA Current Consumption: \u0026lt;10mA\r\nResponse Frequency: 500Hz Voltage: \u0026lt;1.5V Indicator Light: Action indicator\r\n(red LED) Insulation Resistance: \u0026gt;50M? (500VDC megohm reference) Withstand\r\nVoltage: 1500VAC 50\/60Hz 1min Vibration Resistance: 10-55Hz (cycle one minute)\r\namplitude 1mm X, Y, Z 2 hours in each direction Impact Resistance: 500m\/s²\r\n(50G) X, Y, Z 3 times in all directions Operating Environment: -25~+70°C,\r\n35-95%RH Storage Environment: -30~+80°C, 35-95%RH Circuit: Built-in Circuit,\r\nPower Reverse Polarity Circuit, Over Current Circuit Package List: 1 x\r\nPhotoelectric\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eWORKING PRINCIPLE:Photoelectric switch makes use of the block or reflection of the detected object to the light beam, and the circuit is turned on by the synchronous circuit to detect the or absence of the object.\u003c\/li\u003e\r\n \u003cli\u003eWORKING PROCESS:The photoelectric switch converts the input current into a light on the transmitter, and the receiver detects the target object according to the or of the received light.\u003c\/li\u003e\r\n \u003cli\u003eHIGH SENSITIVITY:The sensor uses infrared light to detect the objects for sensitive detection with delay that can be almost ignored.\u003c\/li\u003e\r\n \u003cli\u003eWIDE RANGE OF USES:The detection objects of this photoelectric are not limited to metal, and all objects that reflect light (or block light) can be detected.\u003c\/li\u003e\r\n \u003cli\u003eSAFETY DESIGN:The photoelectric switch converts has built-in multiple circuits to ensure use.\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
