{"id":7975310164148,"title":"Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection","handle":"feekoon-1-pack-ss2-float-switch-l-shape-for-easy-installation-ac-float-switch-with-3-4-inch-adaptor-and-6ft-wire-water-level-accessory-for-hvac-system-with-condensate-overflow-detection","description":"\u003ch3\u003eFeekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eAre you still worried about soaking your furniture due to condensation leaks\nwhen using your HVAC? Then you absolutely need a float switch! Here are the\nspecific installation steps for you: INLINE INSTALLATION FOR (WALL) UNITS WITH\nVERTICAL DRAIN OUTLETS It is recommended that this device be installed on the\nprimary drain line between the pan outlet and P trap on wall units with\nvertical drain outlets. This will prevent the switch from shutting off the fan\ncoil or activating the alarm circuit in the event condensate drips directly\nfrom the coil into the auxiliary pan outlet when the coil becomes dirty. 1.\nDisconnect power to unit at main panel and glue 5'' stub down from the primary\npan outlet. 2. Glue 3\/4'' Tee to bottom of stub with Tee stem horizontal and\nplumb. 3. Glue 3\/4'' stub into horizontal outlet of Tee, insuring it is also\nplumb. 4. Ensure switch\/plug assembly is inserted into 1'' inlet of PVC elbow\nso that float stem is at inside (bottom) of switch elbow. Float stem can be\nadjusted by threading it out of the plug assembly. DO NOT GLUE. 5. Glue a\ndrain line with P trap onto the remaining outlet of Tee. 6. Connect the wires\nto VCC or the thermostat wires. 7. Test switch by lifting float with unit\nrunning. Unit should stop running if correctly connected. 8. Test all fittings\nand connections for plumbing leaks. INSTALLATION FOR HORIZONTAL CEILING\n(PANCAKE) UNITS NOTE: Primary drain (inline) is also recommended on horizontal\nceiling (pancake) units as some flooding may occur if installed on auxiliary\noutlets, due to the closeness of the outlets to the top of the pan. 1. Glue\n3\/4'' stub to primary pan outlet. 2. Glue 3\/4'' Tee onto stub with Tee stem\npositioned horizontally away from the unit and plumb. 3. Follow steps 3-9\nunder INLINE INSTALLATION FOR WALL UNITS, above.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eHVAC Float Switch Function: SS2 water level switch is applied in HVAC systems to detect condensation water overflow; It detects blockage of air conditioning condensate water drain pipe and shuts down the system to prevent overflowing water from damaging floors, walls, and ceilings\u003c\/li\u003e\n \u003cli\u003eWorking Principle: the float switch HVAC can be connected to a VCC or thermostat line; It is an NC type (normally closed) switch: when no water overflows, the float stays at the bottom of the switch, the switch closes the loop and outputs an ON signal; When the water overflows, the buoyancy of the float rises, the trigger switch turns on, and the output OFF signal turns off\u003c\/li\u003e\n \u003cli\u003eSpecifications: switch type NC (normally closed), material PVC, operating temperature -20 - +80C, wire length 5.8ft, switching voltage max; 200VDC; Switching current max; 1 A contact rating maximum 10W\u003c\/li\u003e\n \u003cli\u003eEasy to Install: this float switch HVAC is easy to install, all you need to do is install the 3\/ 4 adapter that comes with the AC float switch on the auxiliary drain outlet of the main panel and connect the 5.8ft of wire to VCC or thermostat wire\u003c\/li\u003e\n \u003cli\u003eEasy to Clean: the transparent material allows you to see what's going on inside; The float switch is equipped with a removable cover; When you use it for some time, you can remove it for cleaning to ensure hygiene and normal function\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-07-26T02:29:51+10:00","created_at":"2025-07-26T02:29:47+10:00","vendor":"Feekoon","type":"Flow Switches","tags":["industrial_best_sellers_Jun2025"],"price":11300,"price_min":11300,"price_max":11300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":43992914100404,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0CZF8FH5F","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection","public_title":null,"options":["Default Title"],"price":11300,"weight":132,"compare_at_price":null,"inventory_management":"shopify","barcode":"DC-Feekoon-414","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/B0CZF8FH5F.jpg?v=1775762367","\/\/auspowers.com\/cdn\/shop\/files\/71sehbhGpPL.jpg?v=1753460990","\/\/auspowers.com\/cdn\/shop\/files\/61BLou-m3rL.jpg?v=1753460990","\/\/auspowers.com\/cdn\/shop\/files\/71EetIbNsAL.jpg?v=1753460991","\/\/auspowers.com\/cdn\/shop\/files\/71SlDmRdDCL.jpg?v=1753460990","\/\/auspowers.com\/cdn\/shop\/files\/71eZycscb-L.jpg?v=1753460991","\/\/auspowers.com\/cdn\/shop\/files\/71xMMjfT80L.jpg?v=1753460990"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/B0CZF8FH5F.jpg?v=1775762367","options":["Title"],"media":[{"alt":"[Australia - AusPower] - Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection ","id":31877557158068,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/B0CZF8FH5F.jpg?v=1775762367"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/B0CZF8FH5F.jpg?v=1775762367","width":2000},{"alt":"[Australia - AusPower] - Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection ","id":31877557190836,"position":2,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71sehbhGpPL.jpg?v=1753460990"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71sehbhGpPL.jpg?v=1753460990","width":2000},{"alt":"[Australia - AusPower] - Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection ","id":31877557223604,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61BLou-m3rL.jpg?v=1753460990"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61BLou-m3rL.jpg?v=1753460990","width":1500},{"alt":"[Australia - AusPower] - Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection ","id":31877557256372,"position":4,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71EetIbNsAL.jpg?v=1753460991"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71EetIbNsAL.jpg?v=1753460991","width":2000},{"alt":"[Australia - AusPower] - Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection ","id":31877557289140,"position":5,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71SlDmRdDCL.jpg?v=1753460990"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71SlDmRdDCL.jpg?v=1753460990","width":2000},{"alt":"[Australia - AusPower] - Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection ","id":31877557321908,"position":6,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71eZycscb-L.jpg?v=1753460991"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71eZycscb-L.jpg?v=1753460991","width":2000},{"alt":"[Australia - AusPower] - Feekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection ","id":31877557354676,"position":7,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71xMMjfT80L.jpg?v=1753460990"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71xMMjfT80L.jpg?v=1753460990","width":2000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eFeekoon 1 Pack SS2 Float Switch L Shape for Easy Installation, AC Float Switch with 3\/4 Inch Adaptor and 6ft wire, Water Level Accessory for Hvac System with Condensate Overflow Detection\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eAre you still worried about soaking your furniture due to condensation leaks\nwhen using your HVAC? Then you absolutely need a float switch! Here are the\nspecific installation steps for you: INLINE INSTALLATION FOR (WALL) UNITS WITH\nVERTICAL DRAIN OUTLETS It is recommended that this device be installed on the\nprimary drain line between the pan outlet and P trap on wall units with\nvertical drain outlets. This will prevent the switch from shutting off the fan\ncoil or activating the alarm circuit in the event condensate drips directly\nfrom the coil into the auxiliary pan outlet when the coil becomes dirty. 1.\nDisconnect power to unit at main panel and glue 5'' stub down from the primary\npan outlet. 2. Glue 3\/4'' Tee to bottom of stub with Tee stem horizontal and\nplumb. 3. Glue 3\/4'' stub into horizontal outlet of Tee, insuring it is also\nplumb. 4. Ensure switch\/plug assembly is inserted into 1'' inlet of PVC elbow\nso that float stem is at inside (bottom) of switch elbow. Float stem can be\nadjusted by threading it out of the plug assembly. DO NOT GLUE. 5. Glue a\ndrain line with P trap onto the remaining outlet of Tee. 6. Connect the wires\nto VCC or the thermostat wires. 7. Test switch by lifting float with unit\nrunning. Unit should stop running if correctly connected. 8. Test all fittings\nand connections for plumbing leaks. INSTALLATION FOR HORIZONTAL CEILING\n(PANCAKE) UNITS NOTE: Primary drain (inline) is also recommended on horizontal\nceiling (pancake) units as some flooding may occur if installed on auxiliary\noutlets, due to the closeness of the outlets to the top of the pan. 1. Glue\n3\/4'' stub to primary pan outlet. 2. Glue 3\/4'' Tee onto stub with Tee stem\npositioned horizontally away from the unit and plumb. 3. Follow steps 3-9\nunder INLINE INSTALLATION FOR WALL UNITS, above.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eHVAC Float Switch Function: SS2 water level switch is applied in HVAC systems to detect condensation water overflow; It detects blockage of air conditioning condensate water drain pipe and shuts down the system to prevent overflowing water from damaging floors, walls, and ceilings\u003c\/li\u003e\n \u003cli\u003eWorking Principle: the float switch HVAC can be connected to a VCC or thermostat line; It is an NC type (normally closed) switch: when no water overflows, the float stays at the bottom of the switch, the switch closes the loop and outputs an ON signal; When the water overflows, the buoyancy of the float rises, the trigger switch turns on, and the output OFF signal turns off\u003c\/li\u003e\n \u003cli\u003eSpecifications: switch type NC (normally closed), material PVC, operating temperature -20 - +80C, wire length 5.8ft, switching voltage max; 200VDC; Switching current max; 1 A contact rating maximum 10W\u003c\/li\u003e\n \u003cli\u003eEasy to Install: this float switch HVAC is easy to install, all you need to do is install the 3\/ 4 adapter that comes with the AC float switch on the auxiliary drain outlet of the main panel and connect the 5.8ft of wire to VCC or thermostat wire\u003c\/li\u003e\n \u003cli\u003eEasy to Clean: the transparent material allows you to see what's going on inside; The float switch is equipped with a removable cover; When you use it for some time, you can remove it for cleaning to ensure hygiene and normal function\u003c\/li\u003e\n \u003c\/ul\u003e"}
