{"id":8115271106740,"title":"DollaTek PWM Signal Generator 1Hz -150kHz Dual Mode Generator Adjustable Pulse Frequency Duty Ratio Duty Rectangular Wave Module with Housing","handle":"dollatek-pwm-signal-generator-1hz-150khz-dual-mode-generator-adjustable-pulse-frequency-duty-ratio-duty-rectangular-wave-module-with-housing","description":"\u003ch3\u003eDollaTek PWM Signal Generator 1Hz -150kHz Dual Mode Generator Adjustable Pulse Frequency Duty Ratio Duty Rectangular Wave Module with Housing\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eParameters: Working voltage: 3.3V ~ 30V, with non-return protection. Frequency\nrange: 1 Hz ~ 150 kHz, accuracy approx. 1%. Working range: 0-100%, 1% step.\nNumber of pulses: 1-9999 or infinity (display '----' stands for infinity).\nDelay output time: 0.000s-9999s, the minimum can be set to 1ms. Positive and\nnegative pulse width length: 0.000s-9999s, the minimum can be set to 1ms.\nSignal charging capacity: less than 30mA Output signal amplitude: The\namplitude corresponds to the supply voltage. Product size: 79 mm x 43 mm x 30\nmm. Feature: PWM mode - Frequency (continuous), duty cycle. Note that the\nnumber of pulses in this mode cannot be set and the pulse is always sent. PULS\nMode - Positive pulse width time, negative pulse width time, delay start time\nand number of pulses are adjustable. Package includes: 1 x PWM signal\ngenerator\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eParameters ---- Working voltage: 3.3V ~ 30V, Frequency range: 1Hz~150KHz, Signal charging capacity: less than 30mA.\u003c\/li\u003e\n \u003cli\u003eDual mode: the signal generator has two modes, PWM and pulse.\u003c\/li\u003e\n \u003cli\u003eProtection: with kickback protection, 5.08 mm terminal wiring.\u003c\/li\u003e\n \u003cli\u003eEasy to use: the signal generator with button can control start or stop and connect the external switch to control the output signal on\/off.\u003c\/li\u003e\n \u003cli\u003eApplication: the generator module can be used to generate rectangular wave rectangular signals to control DC motors or stepper motor drivers. For servo motors, stepper motors, electric jaws instead of PLC pulses, etc.\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2026-09-02T11:18:54+10:00","created_at":"2026-09-01T23:42:47+10:00","vendor":"DollaTek","type":"Function Generators","tags":["industrial_DE_Aug2026"],"price":11300,"price_min":11300,"price_max":11300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44374991372468,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B08P36752V","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"DollaTek PWM Signal Generator 1Hz -150kHz Dual Mode Generator Adjustable Pulse Frequency Duty Ratio Duty Rectangular Wave Module with Housing","public_title":null,"options":["Default Title"],"price":11300,"weight":90,"compare_at_price":null,"inventory_management":"shopify","barcode":"ELA13302","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/B08P36752V.jpg?v=1788270169","\/\/auspowers.com\/cdn\/shop\/files\/61BC87QwMeL.jpg?v=1788270169","\/\/auspowers.com\/cdn\/shop\/files\/61IMrWOamUL.jpg?v=1788270169","\/\/auspowers.com\/cdn\/shop\/files\/619zMo8wQNL.jpg?v=1788270169","\/\/auspowers.com\/cdn\/shop\/files\/61SORJp8OPL.jpg?v=1788270169","\/\/auspowers.com\/cdn\/shop\/files\/51-xin9syVL.jpg?v=1788270169"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/B08P36752V.jpg?v=1788270169","options":["Title"],"media":[{"alt":null,"id":33273143296180,"position":1,"preview_image":{"aspect_ratio":1.479,"height":676,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/B08P36752V.jpg?v=1788270169"},"aspect_ratio":1.479,"height":676,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/B08P36752V.jpg?v=1788270169","width":1000},{"alt":null,"id":33273143328948,"position":2,"preview_image":{"aspect_ratio":1.825,"height":548,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61BC87QwMeL.jpg?v=1788270169"},"aspect_ratio":1.825,"height":548,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61BC87QwMeL.jpg?v=1788270169","width":1000},{"alt":null,"id":33273143361716,"position":3,"preview_image":{"aspect_ratio":1.179,"height":848,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61IMrWOamUL.jpg?v=1788270169"},"aspect_ratio":1.179,"height":848,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61IMrWOamUL.jpg?v=1788270169","width":1000},{"alt":null,"id":33273143394484,"position":4,"preview_image":{"aspect_ratio":1.087,"height":920,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/619zMo8wQNL.jpg?v=1788270169"},"aspect_ratio":1.087,"height":920,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/619zMo8wQNL.jpg?v=1788270169","width":1000},{"alt":null,"id":33273143427252,"position":5,"preview_image":{"aspect_ratio":1.333,"height":750,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61SORJp8OPL.jpg?v=1788270169"},"aspect_ratio":1.333,"height":750,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61SORJp8OPL.jpg?v=1788270169","width":1000},{"alt":null,"id":33273143460020,"position":6,"preview_image":{"aspect_ratio":1.212,"height":825,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/51-xin9syVL.jpg?v=1788270169"},"aspect_ratio":1.212,"height":825,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/51-xin9syVL.jpg?v=1788270169","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eDollaTek PWM Signal Generator 1Hz -150kHz Dual Mode Generator Adjustable Pulse Frequency Duty Ratio Duty Rectangular Wave Module with Housing\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eParameters: Working voltage: 3.3V ~ 30V, with non-return protection. Frequency\nrange: 1 Hz ~ 150 kHz, accuracy approx. 1%. Working range: 0-100%, 1% step.\nNumber of pulses: 1-9999 or infinity (display '----' stands for infinity).\nDelay output time: 0.000s-9999s, the minimum can be set to 1ms. Positive and\nnegative pulse width length: 0.000s-9999s, the minimum can be set to 1ms.\nSignal charging capacity: less than 30mA Output signal amplitude: The\namplitude corresponds to the supply voltage. Product size: 79 mm x 43 mm x 30\nmm. Feature: PWM mode - Frequency (continuous), duty cycle. Note that the\nnumber of pulses in this mode cannot be set and the pulse is always sent. PULS\nMode - Positive pulse width time, negative pulse width time, delay start time\nand number of pulses are adjustable. Package includes: 1 x PWM signal\ngenerator\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eParameters ---- Working voltage: 3.3V ~ 30V, Frequency range: 1Hz~150KHz, Signal charging capacity: less than 30mA.\u003c\/li\u003e\n \u003cli\u003eDual mode: the signal generator has two modes, PWM and pulse.\u003c\/li\u003e\n \u003cli\u003eProtection: with kickback protection, 5.08 mm terminal wiring.\u003c\/li\u003e\n \u003cli\u003eEasy to use: the signal generator with button can control start or stop and connect the external switch to control the output signal on\/off.\u003c\/li\u003e\n \u003cli\u003eApplication: the generator module can be used to generate rectangular wave rectangular signals to control DC motors or stepper motor drivers. For servo motors, stepper motors, electric jaws instead of PLC pulses, etc.\u003c\/li\u003e\n \u003c\/ul\u003e"}
