{"id":8115284148404,"title":"BuyWeek Temperature Control Relay, AC\/DC 24 V-240 V Temperature Controller Relay 35 mm Rail Installation Thermostat Relay with Probe, LED Display High\/Low Temperature Monitoring (GRW8-01)","handle":"buyweek-temperature-control-relay-ac-dc-24-v-240-v-temperature-controller-relay-35-mm-rail-installation-thermostat-relay-with-probe-led-display-high-low-temperature-monitoring-grw8-01","description":"\u003ch3\u003eBuyWeek Temperature Control Relay, AC\/DC 24 V-240 V Temperature Controller Relay 35 mm Rail Installation Thermostat Relay with Probe, LED Display High\/Low Temperature Monitoring (GRW8-01)\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecification Item Type:Temperature Control Relay Function: monitor the\nhigh\/low temperature Power connection: L-N. Rated voltage: AC\/DC 24V-240V.\nRated power frequency: 50\/60Hz. Nominal pulse resisting voltage: 2.5 kV.\nNominal voltage: 250 V. Power consumption: maximum 2 VA. Permissible\nfluctuation range of the power supply: -15% ~ + 10%. Temperature setting\nrange: -15°C to +45°C. Temperature setting hysteresis value: 0.5 °C to 5 °C.\nWorking mode: heating-cooling-on and off can be adjusted. Power indicator:\ngreen LED. Output contact parameters: 1xSPST 16A\/AC1 250VAC\/24VDC Minimum\nswitching capacity: 500 mW. Output relay display: red LED. Mechanical life: 1\nx 10000000. Electrical life (resistance load): 1 x 100000. Working environment\ntemperature: -20 ℃ ~ + 55 ℃. Storage and transport ambient temperature: -35 °C\n~ + 75 °C. Installation method: approx. 35 mm \/ 1.4 inch rail installation.\nProtection level: IP20. Installation location: each Installation height:\nPollution level: 2. Cabling capacity: 1 x 2.5 mm² or 2 x 1.5 mm² 0.8 Nm.\nPackage list: 1 x temperature control relay. 1 x probe. 1 x user manual\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMonitoring: the temperature control relay can select the heating or cooling mode to monitor high or low temperatures and ensure stable operation within the set range\u003c\/li\u003e\n \u003cli\u003eLED indicators: temperature monitoring by LED indicators, users can clearly understand the working status of the relay. The green power indicator shows normal power supply and the red output relay indicator indicates that the relay is activated\u003c\/li\u003e\n \u003cli\u003eWide voltage: the thermostat relay is suitable for supply voltage of AC\/DC from 24 V to 240 V and a rated current supply frequency of 50\/60 Hz and offers a wide applicability\u003c\/li\u003e\n \u003cli\u003eLow power consumption: the maximum current consumption of the temperature controller is only 2VA and the allowable power fluctuation range is -15% to +10%, which ensures the stable operation of the relay under different power conditions\u003c\/li\u003e\n \u003cli\u003eRail Mounting:The temperature control relay features 35mm rail mounting. The relay is compact and easy to carry and store. Meanwhile, it is easy to install and suitable for different occasions\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2026-09-02T11:13:53+10:00","created_at":"2026-09-01T23:47:54+10:00","vendor":"BuyWeek","type":"Temperature Controllers","tags":["industrial_DE_Aug2026"],"price":19900,"price_min":19900,"price_max":19900,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":44375004545204,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B0CX8XMTQW","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"BuyWeek Temperature Control Relay, AC\/DC 24 V-240 V Temperature Controller Relay 35 mm Rail Installation Thermostat Relay with Probe, LED Display High\/Low Temperature Monitoring (GRW8-01)","public_title":null,"options":["Default Title"],"price":19900,"weight":99,"compare_at_price":null,"inventory_management":"shopify","barcode":"BuyWeekzuq9vagemb","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/de-B0CX8XMTQW_b59198a9-e6a0-4f36-a25c-d786affa473f.jpg?v=1788270476","\/\/auspowers.com\/cdn\/shop\/files\/41JRLmX898L.jpg?v=1788270476","\/\/auspowers.com\/cdn\/shop\/files\/513I3FmRR8S.jpg?v=1788270476","\/\/auspowers.com\/cdn\/shop\/files\/41TFWu9Np_L.jpg?v=1788270476","\/\/auspowers.com\/cdn\/shop\/files\/41ll320meOL.jpg?v=1788270476","\/\/auspowers.com\/cdn\/shop\/files\/31MNkM7Q4tL.jpg?v=1788270476","\/\/auspowers.com\/cdn\/shop\/files\/41TpjH-H6rL.jpg?v=1788270476"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/de-B0CX8XMTQW_b59198a9-e6a0-4f36-a25c-d786affa473f.jpg?v=1788270476","options":["Title"],"media":[{"alt":null,"id":33273224724660,"position":1,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/files\/de-B0CX8XMTQW_b59198a9-e6a0-4f36-a25c-d786affa473f.jpg?v=1788270476"},"aspect_ratio":1.0,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/de-B0CX8XMTQW_b59198a9-e6a0-4f36-a25c-d786affa473f.jpg?v=1788270476","width":500},{"alt":null,"id":33273224757428,"position":2,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/files\/41JRLmX898L.jpg?v=1788270476"},"aspect_ratio":1.0,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/41JRLmX898L.jpg?v=1788270476","width":500},{"alt":null,"id":33273224790196,"position":3,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/files\/513I3FmRR8S.jpg?v=1788270476"},"aspect_ratio":1.0,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/513I3FmRR8S.jpg?v=1788270476","width":500},{"alt":null,"id":33273224822964,"position":4,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/files\/41TFWu9Np_L.jpg?v=1788270476"},"aspect_ratio":1.0,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/41TFWu9Np_L.jpg?v=1788270476","width":500},{"alt":null,"id":33273224855732,"position":5,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/files\/41ll320meOL.jpg?v=1788270476"},"aspect_ratio":1.0,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/41ll320meOL.jpg?v=1788270476","width":500},{"alt":null,"id":33273224888500,"position":6,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/files\/31MNkM7Q4tL.jpg?v=1788270476"},"aspect_ratio":1.0,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/31MNkM7Q4tL.jpg?v=1788270476","width":500},{"alt":null,"id":33273224921268,"position":7,"preview_image":{"aspect_ratio":1.0,"height":500,"width":500,"src":"\/\/auspowers.com\/cdn\/shop\/files\/41TpjH-H6rL.jpg?v=1788270476"},"aspect_ratio":1.0,"height":500,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/41TpjH-H6rL.jpg?v=1788270476","width":500}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eBuyWeek Temperature Control Relay, AC\/DC 24 V-240 V Temperature Controller Relay 35 mm Rail Installation Thermostat Relay with Probe, LED Display High\/Low Temperature Monitoring (GRW8-01)\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecification Item Type:Temperature Control Relay Function: monitor the\nhigh\/low temperature Power connection: L-N. Rated voltage: AC\/DC 24V-240V.\nRated power frequency: 50\/60Hz. Nominal pulse resisting voltage: 2.5 kV.\nNominal voltage: 250 V. Power consumption: maximum 2 VA. Permissible\nfluctuation range of the power supply: -15% ~ + 10%. Temperature setting\nrange: -15°C to +45°C. Temperature setting hysteresis value: 0.5 °C to 5 °C.\nWorking mode: heating-cooling-on and off can be adjusted. Power indicator:\ngreen LED. Output contact parameters: 1xSPST 16A\/AC1 250VAC\/24VDC Minimum\nswitching capacity: 500 mW. Output relay display: red LED. Mechanical life: 1\nx 10000000. Electrical life (resistance load): 1 x 100000. Working environment\ntemperature: -20 ℃ ~ + 55 ℃. Storage and transport ambient temperature: -35 °C\n~ + 75 °C. Installation method: approx. 35 mm \/ 1.4 inch rail installation.\nProtection level: IP20. Installation location: each Installation height:\nPollution level: 2. Cabling capacity: 1 x 2.5 mm² or 2 x 1.5 mm² 0.8 Nm.\nPackage list: 1 x temperature control relay. 1 x probe. 1 x user manual\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMonitoring: the temperature control relay can select the heating or cooling mode to monitor high or low temperatures and ensure stable operation within the set range\u003c\/li\u003e\n \u003cli\u003eLED indicators: temperature monitoring by LED indicators, users can clearly understand the working status of the relay. The green power indicator shows normal power supply and the red output relay indicator indicates that the relay is activated\u003c\/li\u003e\n \u003cli\u003eWide voltage: the thermostat relay is suitable for supply voltage of AC\/DC from 24 V to 240 V and a rated current supply frequency of 50\/60 Hz and offers a wide applicability\u003c\/li\u003e\n \u003cli\u003eLow power consumption: the maximum current consumption of the temperature controller is only 2VA and the allowable power fluctuation range is -15% to +10%, which ensures the stable operation of the relay under different power conditions\u003c\/li\u003e\n \u003cli\u003eRail Mounting:The temperature control relay features 35mm rail mounting. The relay is compact and easy to carry and store. Meanwhile, it is easy to install and suitable for different occasions\u003c\/li\u003e\n \u003c\/ul\u003e"}
