{"id":7975304855732,"title":"16 Input 16 Output Expansion Board RS485 16 Channel Remote Control Switch Module DC 6.5 to 30V PLC IO Module for Smart Home With shell","handle":"16-input-16-output-expansion-board-rs485-16-channel-remote-control-switch-module-dc-6-5-to-30v-plc-io-module-for-smart-home-with-shell","description":"\u003ch3\u003e16 Input 16 Output Expansion Board RS485 16 Channel Remote Control Switch Module DC 6.5 to 30V PLC IO Module for Smart Home\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecification: Item Type: Expansion Board Material: PCB Model: N4D3E16 1.\nWorking Voltage: DC 6.5-30V (7.5V 9V 12V 15V 24V) 2. Working Current: 8-50MA\n3. 16 channel isolated input ports (NPN is active at low level) 4. 16 channel\nDarlington outputs (ULN2803 NPN output) 5. 6 commands of open, close,\ninstantaneous, self locking, interlocking and delay 6. 16 channel input can\nremotely control the 16 channel output of another board through the RS485 bus\n(relevant registers need to be set) 7. For RTU instruction, support 03 06\nfunction codes (some registers support 16 function codes) 8. Under the Delay\ncommand, the maximum delay is 255 seconds 9. You can press Enter in the serial\nport super terminal (serial port assistant) 10. Up to 64 devices can be\nconnected in parallel 11. The default baud rate is 9600BPS, and the baud rate\ncan be selected by jumpers: 2400 4800 9600 19200BPS Maximum Load: The maximum\nload current of each channel is 300MA DIN Rail Box Parameters: Model: UM72\nColor: Green Width: Suitable for PCB board width UM72 (Approx. 72mm \/ 2.8in)\nInsulation Grade: Flame retardant VO grade Backplane Length: Suitable for\napprox. 100mm \/ 3.9in PCB board Installation Method: DIN35 and C45 rails\nPackage List: 1 x Expansion Board Note: Please use it within the specified\nvoltage and current range.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003e16 IN 16 OUT: PLC expansion board 16 channel input can remotely control 16 channels of output of another board via RS485 bus (relevant registers need to be set)\u003c\/li\u003e\n \u003cli\u003eAPPLICATION: 16 Channel RS485 module is widely used in PLC IO expansion board, smart home, home automation, camera, security surveillance, identification system, network camera, LED light driver and automatic curtain control\u003c\/li\u003e\n \u003cli\u003eMULTIFUNCTION: 16 input 16 output expansion board has 6 commands, namely open, close, instantaneous, self locking, interlocking and delay, with strong functionality, can meet your uisng requirement\u003c\/li\u003e\n \u003cli\u003eEASY INSTALLATION: The power expansion module is small and compact, with mounting holes, DIN35 and C45 rail installation design, backplane length is suitable for about 100mm \/ 3.9in PCB board\u003c\/li\u003e\n \u003cli\u003eSIMPLE WIRING: The 16 channel expansion board circuit has been repeatedly debugged, the PCB wiring is simple and there is little interference, convenient to use\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-07-26T02:19:23+10:00","created_at":"2025-07-26T02:19:19+10:00","vendor":"LiebeWH","type":"IO Modules","tags":["industrial_best_sellers_Jun2025"],"price":13100,"price_min":13100,"price_max":13100,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":43992903549108,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B09RB77YS9","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16 Input 16 Output Expansion Board RS485 16 Channel Remote Control Switch Module DC 6.5 to 30V PLC IO Module for Smart Home With shell","public_title":null,"options":["Default Title"],"price":13100,"weight":140,"compare_at_price":null,"inventory_management":"shopify","barcode":"LiebeWHe5ubqa4h7m2567-12","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/auspowers.com\/cdn\/shop\/files\/B09RB77YS9.jpg?v=1775762135","\/\/auspowers.com\/cdn\/shop\/files\/71rd6ogUIkL.jpg?v=1753460363","\/\/auspowers.com\/cdn\/shop\/files\/716iERin5lL.jpg?v=1753460362","\/\/auspowers.com\/cdn\/shop\/files\/71vkec3CRVL.jpg?v=1753460362","\/\/auspowers.com\/cdn\/shop\/files\/61-Up6M0K0L.jpg?v=1753460362","\/\/auspowers.com\/cdn\/shop\/files\/61ZUaVQ3k9L.jpg?v=1753460362","\/\/auspowers.com\/cdn\/shop\/files\/71Fyjh4QpnL.jpg?v=1753460363","\/\/auspowers.com\/cdn\/shop\/files\/71PupjXHz1L.jpg?v=1753460363","\/\/auspowers.com\/cdn\/shop\/files\/71QsIGo0fcL.jpg?v=1753460363"],"featured_image":"\/\/auspowers.com\/cdn\/shop\/files\/B09RB77YS9.jpg?v=1775762135","options":["Title"],"media":[{"alt":"LiebeWH 16-channel RS485 IO expansion board with shell, remote control switch module for smart home, DC 6.5-30V PLC IO.","id":31877529731252,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/B09RB77YS9.jpg?v=1775762135"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/B09RB77YS9.jpg?v=1775762135","width":1601},{"alt":"LiebeWH 16-channel RS485 expansion board with remote control switch module, DC 6.5-30V, for smart home PLC IO applications.","id":31877529764020,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71rd6ogUIkL.jpg?v=1753460363"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71rd6ogUIkL.jpg?v=1753460363","width":1600},{"alt":"LiebeWH 16-channel RS485 expansion board with shell, remote control switch module for smart home PLC IO, DC 6.5-30V.","id":31877529796788,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/716iERin5lL.jpg?v=1753460362"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/716iERin5lL.jpg?v=1753460362","width":1601},{"alt":"LiebeWH 16-channel RS485 IO expansion board with remote control switches, DC 6.5-30V, for smart home automation, with protective shell.","id":31877529829556,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71vkec3CRVL.jpg?v=1753460362"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71vkec3CRVL.jpg?v=1753460362","width":1601},{"alt":"LiebeWH 16-channel RS485 expansion board with remote control switch module, suitable for smart home PLC applications with shell enclosure.","id":31877529862324,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61-Up6M0K0L.jpg?v=1753460362"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61-Up6M0K0L.jpg?v=1753460362","width":1601},{"alt":"LiebeWH 16-channel RS485 expansion board with shell, featuring 16 input\/output channels and remote control switch module for smart home use","id":31877529895092,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/auspowers.com\/cdn\/shop\/files\/61ZUaVQ3k9L.jpg?v=1753460362"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/61ZUaVQ3k9L.jpg?v=1753460362","width":1000},{"alt":"LiebeWH 16-channel RS485 expansion board with remote control switch module, DC 6.5-30V, PLC IO module for smart home applications.","id":31877529927860,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71Fyjh4QpnL.jpg?v=1753460363"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71Fyjh4QpnL.jpg?v=1753460363","width":1601},{"alt":"LiebeWH 16-channel RS485 expansion board with remote control switch module, suitable for smart home PLC IO applications.","id":31877529960628,"position":8,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71PupjXHz1L.jpg?v=1753460363"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71PupjXHz1L.jpg?v=1753460363","width":1601},{"alt":"LiebeWH 16-channel RS485 expansion board with remote control switch module, DC 6.5-30V PLC IO module with shell for smart home use","id":31877529993396,"position":9,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/auspowers.com\/cdn\/shop\/files\/71QsIGo0fcL.jpg?v=1753460363"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/auspowers.com\/cdn\/shop\/files\/71QsIGo0fcL.jpg?v=1753460363","width":1601}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003e16 Input 16 Output Expansion Board RS485 16 Channel Remote Control Switch Module DC 6.5 to 30V PLC IO Module for Smart Home\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecification: Item Type: Expansion Board Material: PCB Model: N4D3E16 1.\nWorking Voltage: DC 6.5-30V (7.5V 9V 12V 15V 24V) 2. Working Current: 8-50MA\n3. 16 channel isolated input ports (NPN is active at low level) 4. 16 channel\nDarlington outputs (ULN2803 NPN output) 5. 6 commands of open, close,\ninstantaneous, self locking, interlocking and delay 6. 16 channel input can\nremotely control the 16 channel output of another board through the RS485 bus\n(relevant registers need to be set) 7. For RTU instruction, support 03 06\nfunction codes (some registers support 16 function codes) 8. Under the Delay\ncommand, the maximum delay is 255 seconds 9. You can press Enter in the serial\nport super terminal (serial port assistant) 10. Up to 64 devices can be\nconnected in parallel 11. The default baud rate is 9600BPS, and the baud rate\ncan be selected by jumpers: 2400 4800 9600 19200BPS Maximum Load: The maximum\nload current of each channel is 300MA DIN Rail Box Parameters: Model: UM72\nColor: Green Width: Suitable for PCB board width UM72 (Approx. 72mm \/ 2.8in)\nInsulation Grade: Flame retardant VO grade Backplane Length: Suitable for\napprox. 100mm \/ 3.9in PCB board Installation Method: DIN35 and C45 rails\nPackage List: 1 x Expansion Board Note: Please use it within the specified\nvoltage and current range.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003e16 IN 16 OUT: PLC expansion board 16 channel input can remotely control 16 channels of output of another board via RS485 bus (relevant registers need to be set)\u003c\/li\u003e\n \u003cli\u003eAPPLICATION: 16 Channel RS485 module is widely used in PLC IO expansion board, smart home, home automation, camera, security surveillance, identification system, network camera, LED light driver and automatic curtain control\u003c\/li\u003e\n \u003cli\u003eMULTIFUNCTION: 16 input 16 output expansion board has 6 commands, namely open, close, instantaneous, self locking, interlocking and delay, with strong functionality, can meet your uisng requirement\u003c\/li\u003e\n \u003cli\u003eEASY INSTALLATION: The power expansion module is small and compact, with mounting holes, DIN35 and C45 rail installation design, backplane length is suitable for about 100mm \/ 3.9in PCB board\u003c\/li\u003e\n \u003cli\u003eSIMPLE WIRING: The 16 channel expansion board circuit has been repeatedly debugged, the PCB wiring is simple and there is little interference, convenient to use\u003c\/li\u003e\n \u003c\/ul\u003e"}
