1-3/8 x 1-3/8 x 1-3/16 Inch V-Block and Clamp Multi-Use Hardened Steel Machinist Set
1-3/8 x 1-3/8 x 1-3/16 Inch V-Block and Clamp Multi-Use Hardened Steel Machinist Set
V-Block and Clamp Machinist Set Specifications: Vee Angle: 90 Degree Vee Capacity: 19/32" Overall Length: 1-3/8" Product Width: 1-3/8" Product Height: 1-3/16" Feature: Stepped groove construction Centered 90-degree V grooves Parallel and square with all surfaces within 0.0003" Made of hardened steel, top quality hardness: HRC58-60 Package includes: 2 x V-Block and Clamp 1 x Wooden Box
Product Features
- V Blocks
- Size (L x W x H): 1-3/8 x 1-3/8 x 1-3/16Inch; Capacity: 19/32In, overall length: 1-3/8In, product width: 1-3/8In, product height: 1-3/16In; clamps are included
- Made of hardened and ground chrome steel
- V block clamp set ; 90 degree Vee blocks
- V groove accuracy are central, parallel and square with all surfaces within 0.0003Inch
- All sides are ground square and parallel to each other
